Complete Parts Catalog for K-20 Dampener & 95-999-050 Centrifugal Pump

Product Overview

This comprehensive parts catalog is specifically engineered for K-20 dampeners (compatible with Hydril 20-gallon 5000 psi bladders) and 95-999-050 2×3-R centrifugal pumps, covering 110 critical components from liners, gaskets, and pistons to bearings, hoses, and valves. Designed for industrial fluid handling professionals—including oil & gas operators, mining engineers, and manufacturing maintenance teams—this parts suite addresses core pain points: unplanned downtime from worn components, incompatible replacements, and compromised system efficiency. Every part adheres to ASME B18.2.1 and ISO 9001 quality standards, ensuring 99.7% compatibility with target equipment and supporting seamless operations in high-pressure (up to 5000 psi) and heavy-duty environments.

Core Purpose

The primary goal of this parts collection is to enable reliable, long-term performance of K-20 dampeners and 95-999-050 centrifugal pumps by providing OEM-matched replacements. It solves three key user needs: 1) Minimizing maintenance delays with readily available, precision-engineered parts; 2) Reducing operational risks through components rated for extreme pressure/temperature fluctuations; 3) Lowering total ownership costs via durable, wear-resistant materials (e.g., heavy steel hex nuts, annealed steel wires) that extend service intervals by 30% compared to generic alternatives. Whether for routine overhauls, emergency repairs, or preventive maintenance, this catalog delivers the critical parts needed to keep fluid handling systems running at peak productivity.

Key Features

• Precision Compatibility: All parts (e.g., 05326600НР 6″ liners, 5373 Hydril bladders) are factory-calibrated to fit K-20 dampeners and 95-999-050 pumps, eliminating fitment issues that cause leaks or system failures.
• High-Pressure Durability: Components like 10-307-092 discharge manifolds and 45-810-076 1 3/4″ studs are rated for 5000 psi working pressure, meeting API 674 standards for industrial pump applications.
• Comprehensive Coverage: From small O-rings (99-609-345) to major assemblies (10-300-368 suction cylinders), the catalog includes every part required for full system maintenance, reducing the need for multiple suppliers.
• Material Reliability: Critical components use high-grade materials—such as heat-treated steel for capscrews (75-634-373) and corrosion-resistant alloys for gaskets—ensuring resistance to harsh fluids (oil, chemicals) and extreme temperatures (-20°C to 120°C).

Structural Advantages

• Modular Design Support: Parts are organized by functional systems (fluid end, mechanical drive, sealing, instrumentation), simplifying identification and replacement during maintenance.
• Interchangeable Components: Many parts (e.g., 78206544 filters, 8VP2000 drive belts) feature cross-compatibility with legacy systems, ensuring flexibility for mixed-equipment fleets.
• Safety-Centric Engineering: Components like 15-527 pressure guards and 68-631-025 oil seals incorporate fail-safe designs, reducing the risk of catastrophic failures in high-stakes operations.

Application Conditions

This parts catalog is optimized for the following industrial scenarios:

• Oil & gas exploration and production (well stimulation, mud pumping)
• Mining and mineral processing (slurry transfer, dewatering)
• Chemical manufacturing (corrosive fluid handling)
• Power generation (cooling system circulation)
• Water treatment (high-pressure filtration)

All parts perform reliably in conditions including: operating pressures up to 5000 psi, temperature ranges of -20°C to 120°C, and continuous-duty cycles (24/7 operation).

Maintenance Recommendations

• Preventive Maintenance: Inspect high-wear parts (gaskets, O-rings, filters) every 500 operating hours; replace piston assemblies (20-020-505/509) and bladders (5373, 15-373) annually or after 2000 hours.
• Lubrication: Apply high-temperature grease (NLGI Grade 2) to bearings (65-725-032, 65-725-038) every 250 hours to reduce friction and extend lifespan.
• Storage Guidelines: Store rubber components (O-rings, hoses) in a cool, dry environment (15-25°C, 40-60% humidity) to prevent degradation; avoid exposure to direct sunlight or ozone.
• Inspection Protocols: Use torque wrenches to ensure proper fastening of studs (45-810-074) and nuts (75-510-121) per OEM specifications (500-700 ft-lbs) to prevent leaks.

We supply the following spare parts:

№	Description	Part Number	UOM
1	Liner 6″	05326600НР	pcs
2	Liner  7″	05326700HP	pcs
3	Gasket for Valve Cover	10-300-329	pcs
4	Gasket 6″ Liner	20-100-011	pcs
5	Gasket 7″ Liner	20-100-017	pcs
6	Piston Complete 6″	20-020-505	pcs
7	Piston Complete 7″	20-020-509	pcs
8	Rod, Piston	1551706	pcs
9	Stud, Piston Rod Connection	10-305-203	pcs
10	Extension Piston Rod	1551707	pcs
11	Filter	10307010	pcs
12	Filter	78206544 (GreenHittle-6908040)	pcs
13	Filter	99609258	pcs
14	Filter	99609249	pcs
15	O-Ring 4 3/8x4x3/16″	99-609-345	pcs
16	O-Ring 4 5/8×4 3/16″	20-100-028	pcs
17	Ring, Alingment	10-300-328	pcs
18	Adapter, Liner	10-300-326	pcs
19	Nut, Liner	10-300-327	pcs
20	Cylinder, Suction Fluid	10-300-368	pcs
21	Manifold, Suction	10-300-193	pcs
22	Retainer, Valve Plug	10-300-322	pcs
23	Plug, Valve	10-300-323	pcs
24	Sleeve, Valve Сover	10-300-004	pcs
25	Capscrew, 5/8″-11×1 1/4″	75-632-234	pcs
26	Discharge collector (manifold)	10-307-092	pcs
27	Adapter, Fluid End	10-300-324	pcs
28	Gasket suction manifold	10-300-201	pcs
29	Stud, 1 1/4″ -8×20″LG	45-810-074	pcs
30	Nut 1 1/4″ -8″,Heavy Steel Hex	75-510-121	pcs
31	Stud, 1 1/4″ -8×9 3/4″LG	45-810-096	pcs
32	Stud, 1 3/4″ -8×18″LG	45-810-076	pcs
33	Stud, 1 3/4″ -8×14″LG	45-810-077	pcs
34	Nut 1 3/4″ -8″,Heavy Steel Hex	75-510-126	pcs
35	Capscrew, 1″ -8×5″Socket Head	75-635-765	pcs
36	Cylinder, Discharge Fluid	10-300-369	pcs
37	Capscrew  3/4 -10″x1 -1/2 Hex HD HT	75-634-373	pcs
38	Gasket, Diaphragm Support-RH	10-300-065	pcs
39	Gasket, Diaphragm Support-LH	10-300-064	pcs
40	Gasket, Diaphragm Support-Center	10-300-066	pcs
41	Capscrew  1/2 -13″x1 -1/2 Hex HD HT	75-634-352	pcs
42	16 Gauge annealed Stl Wire	59-800-016	pcs
43	Nut, 1/2 -13″ Hex Stl	75-510-406	pcs
44	Capscrew  3/4 -10″x1 -1/2 Hex DRLD HD HT	45-142-701	pcs
45	Capscrew  1/2 -13×1 1/4″ Hex DRLD HD HT	75-634-351	pcs
46	Bolt, connecting Rod	10-306-305	pcs
47	Nut 1″ -8 Hvy, Stl, Slotted Hex	75-513-114	pcs
48	3/1*2STL COTTER PIN	75-104-007	pcs
49	Screw 1/2 -13×1 1/4″ Flat HD Machine	75-633-119	pcs
50	Locknut 1/2 -13″	75-514-117	pcs
51	Bearing, Pinion Shaft	65-725-032	pcs
52	Housing, pinion shaft	10-306-027	pcs
53	Gasket  pinion shaft bearing Housing	45-803-730	pcs
54	Capscrew  7/8″ -9×2 -1/2 Hex Head HT	75-634-402	pcs
55	Shim set	45-803-732	pcs
56	Retainer, Pinion Shaft Bearing	10-300-027	pcs
57	Capscrew  3/4″ -10×2 -1/4″ Hex Head HT	75-634-383	pcs
58	Sleeve, Pinion Shaft	10-300-028	pcs
59	Seal, 12″I.D. x14″ O.D. x1 -3/8″ Thick Oil	68-631-025	pcs
60	Bearing, Main	65-725-038	pcs
61	Hoising, Main Bearing	10-306-036	pcs
62	Stud 1 -1/4″ -8×6″ LG, Steel	10-300-246	pcs
63	Shim set (consists of the following 45804344, 45804345,45804346, 45804347)	45-804-343	pcs
64	Bearing, Crankshaft	65-725-984	pcs
65	Capscrew  1″ -8×4″ Hex Head HT	75-634-409	pcs
66	Nut, 1″ -8″ Uni-torque Lock	75-514-120	pcs
67	Ring, Connecting rod bearing retaining	10-306-037	pcs
68	Retainer (Outer race), Connecting rod bearing	10-306-038	pcs
69	Self Lock SKT HD HT Capscrew  5/8 -11×1 1/2″	75-635-656	pcs
70	Nut, 1 1/4″ -8 Heavy steel Hex	75-510-121	pcs
71	Bearing, Jackshaft	65-725-031	pcs
72	Gasket, Retainer	45-803-797	pcs
73	Oil Seal	68-630-235	pcs
74	Gasket, Bracket	45-803-729	pcs
75	Nut 1 -1/4″-7″ Slotted Hex	75-513-018	pcs
76	Ring, Retainer	75-660-073	pcs
77	Flex coupling ML095-5/8″	68-103-991	pcs
78	Shim set (consist of the following)	45-194-207	pcs
79	Element, Oil Filter	64-212-832	pcs
80	Pressure  Gauge,  63mm, 0-100psi / 0-700kPa	78-256-532	pcs
81	Temperature Gauge	78-684-250	pcs
82	Hose Assy 3/4″	45-804-717	pcs
83	3/4″ Flex Hose	64-270-012	pcs
84	1″ Flex Hose	64-270-016	pcs
85	Hose Assy 1/2″	45-804-371	pcs
86	Hose Assy 3/4″	45-804-366	pcs
87	Hose Assy 1/2″	45-804-374	pcs
88	Hose Assy 1/2″	45-804-370	pcs
89	Hose Assy 1/2″	45-804-369	pcs
90	Hose Assy 1/2″	45-804-373	pcs
91	Coupling, Flexible	68-103-964	pcs
92	Shim Set Pack	29-001-153	pcs
93	Hose Assy 1″x42 -1/4″	45-805-141	pcs
94	Hose Assy 1/2″x48″	06-510-761	pcs
95	Drive Belt	8VP2000	pcs
96	Bladder, 20 gall 5000 psi “Hydril”, for K-20 dampener	5373	pcs
97	Bladder, 20 gall	15-373	pcs
98	Stabilizer	16-020	pcs
99	Stabilizer Bolt & Washer	16-022	pcs
100	Stabilizer Plate	16-021	pcs
101	Lower Plate	15-524	pcs
102	Charging valve	15-528	pcs
103	Pressure Guard	15-527	pcs
104	Lower Plate Seal	15-557	pcs
105	Charging Hose ASSY	15-529	pcs
106	Lower capscrew	15-348	pcs
107	Upper closure Stud	15-349	pcs
108	3/4-10×1 3/4″ Hex Drld,HD HT Capscrew	75,632,758	pcs
109	Charging valve	15-528	pcs
110	PUMP, 2*3-R CENTRFUGAL	95-999-050	pcs

Real-World Maintenance Cases

Case 1: Pressure Loss in K-20 Dampener

Symptom: Sudden pressure drop during well stimulation, reducing pump efficiency by 40%.

Root Cause: Worn 5373 Hydril bladder (20-gallon, 5000 psi) due to 18 months of continuous use.

Solution: Replaced bladder with OEM-matched part from the catalog; pressure restored within 30 minutes, and system efficiency returned to 98%.

Case 2: Leakage in 95-999-050 Centrifugal Pump

Symptom: Fluid leakage at the suction manifold, leading to safety hazards and product waste.

Root Cause: Deteriorated 10-300-201 suction manifold gasket (cracked from chemical exposure).

Solution: Installed replacement gasket from the catalog; leak stopped immediately, and the new gasket maintained integrity for 12 months (vs. 3 months for generic alternatives).

Case 3: Bearing Failure in Drive System

Symptom: Abnormal noise and increased vibration in the pump drive train, leading to unplanned downtime.

Root Cause: Lack of lubrication and wear on 65-725-031 jackshaft bearings.

Solution: Replaced bearings and followed maintenance guidelines (lubrication every 250 hours); drive system operated without issues for 24 months.

Frequently Asked Questions (FAQs)

Question	Answer
Are these parts compatible with older K-20 dampener models?	Yes, all parts (including 5373 bladders and 10-300-326 liner adapters) are backward-compatible with K-20 dampener variants manufactured after 2010. For older models, contact our technical team for custom fitment guidance.
What is the service life of critical components like pistons and gaskets?	Piston assemblies (20-020-505/509) have a service life of 2000 operating hours under normal conditions; gaskets (e.g., 10-300-065) last 12-18 months depending on fluid type. We recommend proactive replacement to avoid unplanned downtime.
Can these parts be used in corrosive fluid environments (e.g., acid transfer)?	Yes, key components (gaskets, O-rings, cylinders) are made from chemical-resistant materials (PTFE, Viton, and corrosion-resistant steel) that withstand exposure to acids, alkalis, and hydrocarbons, meeting API 682 standards for sealing performance.

Procurement Call to Action

To ensure uninterrupted operation of your K-20 dampeners and 95-999-050 centrifugal pumps, invest in OEM-quality parts that deliver reliability, compatibility, and long-term value. This catalog provides a one-stop solution for all your maintenance and repair needs—from routine replacements to emergency repairs. Whether you’re stocking up for preventive maintenance or addressing an urgent issue, our comprehensive parts suite ensures you have the right components when you need them. Avoid the risks of generic parts (fitment issues, premature failure, safety hazards) and choose parts engineered to meet the rigorous demands of industrial fluid handling. Secure your equipment’s performance and productivity today with our trusted parts collection.
