Detailed Product Introduction
This Halliburton cementing unit parts collection covers all mission-critical subsystems: pressure gauges (0-30/50/60/200/5000 PSI), air regulator components, rubber seals and O-rings (90 durometer, FMC 1502 rated), rotary cement valve hardware, RCM IIIR mixer inserts and wear rings, low-torque (Lo-Torc) valve repair kits, diaphragm protectors, and specialized fasteners. Each item is cross-referenced to original Halliburton part numbers, ensuring perfect drop-in fit and consistent performance with factory cementing unit assemblies.
The parts are curated to address high-failure points of Halliburton cementing equipment, including sealing components, pressure monitoring gauges, mixer wear parts, and valve repair kits. All pressure-containing parts are hydrostatically tested to rated working pressures, while rubber seals use wear-resistant nitrile and Teflon materials to withstand abrasive cement slurry and harsh oilfield chemicals.
Functional Performance & Value Highlights
- Eliminate Cementing Downtime: OEM-matched parts cut repair and replacement time by 60%, preventing costly delays in well cementing operations and ensuring wellbore integrity deadlines are met.
- Precise Pressure Monitoring: Calibrated pressure gauges maintain ±1% accuracy across full PSI ranges, enabling safe and consistent pressure control during cement blending and pumping.
- Leak-Proof Sealing Reliability: 90 durometer O-rings and FMC 1502-rated seals provide zero-leak performance at high pressures, eliminating slurry loss and safety hazards.
- Extended Mixer & Valve Lifespan: Teflon wear rings and RCM IIIR mixer inserts resist abrasion from cement slurry, doubling the service life of generic aftermarket parts and reducing long-term replacement costs.
Structural & Engineering Features
- Halliburton-Exclusive Drop-In Fit: Exact replacements for original cementing unit components, no custom machining or modification required for installation.
- High-Pressure Durability: Components rated for up to 5000 PSI system pressure, built to withstand the extreme demands of high-volume cement pumping.
- Abrasion-Resistant Materials: Teflon wear parts, nitrile rubber seals, and corrosion-resistant fasteners withstand abrasive cement slurry and harsh environmental conditions.
- Subsystem Grouping: Parts organized by gauge & regulator, valve & seal, mixer components, and hardware for targeted sourcing and streamlined inventory management.
Applicable Operating Conditions
- These Halliburton cementing unit parts are engineered for harsh onshore and offshore well cementing environments where reliability and precision are critical, including:
- Onshore well cementing operations with high-volume slurry mixing and pumping
- Offshore platform cementing skids with strict pressure safety and leak-prevention requirements
- Remote cementing sites with dust, moisture, and abrasive cement slurry exposure
- High-pressure cementing systems operating up to 5000 PSI system pressure
- RCM IIIR recirculating cement mixer maintenance and repair
Professional Maintenance & Troubleshooting Recommendations
- Pre-Installation Seal Inspection: Verify seal durometer (90 durometer for O-rings) and part compatibility to prevent premature seal failure and leaks.
- Gauge Calibration Check: Calibrate all pressure gauges post-installation to maintain ±1% accuracy, ensuring reliable pressure monitoring during cementing.
- Valve Repair Protocol: Use complete Lo-Torc redress kits for valve repairs, replacing all seals and wear parts at once to avoid repeat failures.
- Mixer Wear Part Replacement: Inspect RCM IIIR mixer inserts and Teflon wear rings every 500 operating hours, replacing worn parts to maintain mixing efficiency.
- Pressure Testing Compliance: Conduct hydrostatic pressure testing on valves and seals post-installation to confirm rated PSI performance and safety.
We supply the following spare parts:
| ITEM NO | PART NO | DESCRIPTION | Unit |
| 1 | 100033498 | SPRING-AIR-RUBBER-6.0 OD MAX | Ea |
| 2 | 100050505 | BELLOPHRAM HOUSING | Ea |
| 3 | 100002388 | SEAL-RUBBER-RELIEF VALVE-STEADY | Ea |
| 4 | 100003355 | 0 – 60 PSI AIR GAUGE FOR SFB P-READING | Ea |
| 5 | 100001751 | 0 – 30 PSI AIR GAUGE FOR 1″ REGULATOR | Ea |
| 6 | 100001746 | 0 -50 PSI AIR GAUGE, 1/8″ REGULATOR PINCH VLV | Ea |
| 7 | 100005077 | HATCH SEAL, RUBBER | Ea |
| 8 | 100027688 | REGULATOR – AIR – 1 IN. NPT – 0-30 PSI | Ea |
| 9 | 100012954 | ROTARY CEMENT VALVE – 0 RINGS | Ea |
| 10 | 100013260 | R,WR,F/ 6 IN DIA ROD,1/2 IN WIDE | Ea |
| 11 | 100003223 | BDY,VAC BKR,5 IN,RECIRCULATING CEM MIXR | Ea |
| 12 | 100000995 | POPPET ASSY,REPL,2 IN 300 SER,CHK VLV | Ea |
| 13 | 100026440 | NUT,ELAS STP,3/8-16 NC,LT,PL,SPEC | Ea |
| 14 | 100028242 | SCR,HEX SOC,3/8-16 NC X 1 1/2,SPEC | Ea |
| 15 | 100059705 | PLUG,MTR,CEM THROTNG V,LOW PF,90 DEG | Ea |
| 16 | 100013261 | CPLG ASSY,125 MM FLG WTH 1.25 IN BORE | Ea |
| 17 | 101208098 | SHEATH,SPLASH,MIXER,72 DEG OPG,95/16 IN | Ea |
| 18 | 101207817 | SLV,JET,ROT JET WTR VLV,27 HOLE PATT | Ea |
| 19 | 101207818 | PLUG – METERING – ROTARY WATER VALVE – F | Ea |
| 20 | 101208095 | RING – WEAR – TEFLON – F/METERING PLUG | Ea |
| 21 | 100001962 | O-RING,90 DURO,2 7/8 X 2 1/2 X 3/16 | Ea |
| 22 | 100001957 | O-RING,90 DURO,2 3/8 X 2 X 3/16 568-329 | Ea |
| 23 | 101216037 | INSERT,MIXER,RCM IIIR,8.5 IN LONG | Ea |
| 24 | 100001023 | 1″ LOTORC REDRESS KIT | Ea |
| 25 | 100001025 | KIT,SEAL,NIT,1 IN LTQ PLUG V | Ea |
| 26 | 100001015 | 1.75″ LO – TORQUE PLUGS | Ea |
| 27 | 100001017 | 1.75″ LO-TORC REDRESS KIT | Ea |
| 28 | 100001837 | LUBE,V,LTQ,STICK,WTH MOLY,SPCL | Ea |
| 29 | 100001274 | FMC 1502 2″ SEALS | Ea |
| 30 | 101008392 | FMC 1502 3″ SEALS | Ea |
| 31 | 100003355 | 0 – 60 PSI AIR GAUGE,READING S.F.B.PRESSURE | Ea |
| 32 | 100001751 | 0 – 30 PSI AIR GAUGE FOR 1″ REGULATOR | Ea |
| 33 | 100025047 | 0-200 PSI GAUGE,4X4 DISCH PRESS | Ea |
| 34 | 100003351 | 0-5000PSI SYS PRESSURE GAUGE, (4X4, 6X5) | Ea |
| 35 | 100001793 | HOSE 180″ | Ea |
| 36 | 100003377 | DIAPHRAGM GAUGE PROTECTOR F/2″ NITRILE | Ea |
| 37 | 100003375 | MARTIN DECKER PENS BIG RED | Ea |
| 38 | 100002989 | Adapter, Stop and String | Ea |
| 39 | 100010157 | Top Guide | Ea |
| 40 | 100007829 | Pump/Ramp Assembley | Ea |
n-Site Cementing Unit Fault Repair Cases
Case 1: Cement Mixer Pressure Seal Leak
A Halliburton RCM IIIR cement mixer experienced severe slurry leaks at the rotary valve, halting blending operations. The issue was traced to worn 90 durometer O-rings (100001962) and damaged FMC 1502 seals. Replacing these OEM seals eliminated leaks, restoring full mixer functionality and resuming cementing within 90 minutes.
Case 2: Inaccurate Pressure Gauge Readings
Cementing crew reported faulty pressure readings from the 0-60 PSI air gauge (100003355), leading to inconsistent air regulation and poor slurry mixing. Swapping the defective gauge with a calibrated OEM unit restored accurate pressure monitoring, fixing blending consistency and ensuring safe operation.
Case 3: Lo-Torc Valve Wear Failure
A 1.75” Lo-Torc plug valve seized during cement pumping, causing a complete shutdown. Inspection revealed worn internal components, resolved by installing a full Lo-Torc redress kit (100001017). The repair restored smooth valve operation, avoiding costly well cementing delays.
Frequently Asked Questions (FAQ)
| Question | Answer |
| Are these parts compatible only with Halliburton cementing units, or other brands? | These parts are exclusively designed for Halliburton cementing units, including RCM IIIR mixers and standard cementing skids. They are not guaranteed to fit other cementing equipment brands due to unique dimensional and pressure-rated design differences. |
| Do the seals and gauges meet API and Halliburton factory pressure standards? | Yes, all seals comply with FMC 1502 and API 510 standards, and pressure gauges are calibrated to Halliburton’s factory accuracy specs, ensuring safe performance up to 5000 PSI. |
| Can I purchase individual seals or gauges, or only full repair kits? | Parts are available for individual purchase (seals, gauges, hardware) and as complete valve/mixer repair kits, allowing targeted minor repairs or full unit overhauls as needed. |
Procurement Guidance & Call to Action
For cementing operations supervisors, rig maintenance teams, and oilfield procurement specialists managing Halliburton cementing units, this parts list is the definitive resource to reduce downtime, ensure regulatory compliance, and source guaranteed OEM-compatible components. Avoid the risks of substandard generic parts, dangerous pressure leaks, and failed cementing operations — this catalog serves as both a standardized procurement blueprint and technical repair reference for all critical cementing unit systems.
Secure these Halliburton cementing unit parts to execute fast, durable field repairs, maintain precise cement blending and pressure control, and uphold the highest oilfield safety and wellbore integrity standards. Each component is built to withstand the rigors of heavy-duty cementing operations, making this the trusted choice for keeping your Halliburton cementing equipment operating efficiently and reliably.
