Product Introduction
Our MPT-200 tool frame parts lineup encompasses all mechanical wear, transmission, and control components for the complete tool frame assembly, including self-lubricating flange bearings, heavy-duty leaf chains, Polypenco glide pads, AMPCO alloy bushings, radial/angular contact ball bearings, die sets, wear plates, and electrical control accessories. Crafted from self-lubricating composite materials, high-strength alloy steel, wear-resistant AMPCO 18/45 bronze, and industrial-grade polymers, each component undergoes load testing, wear verification, and dimensional inspection to match OEM performance standards. This comprehensive selection supports full tool frame overhauls, targeted wear part replacements, and hydraulic roughneck/spinning wrench repairs, making it the definitive sourcing solution for MPT-200 tool frame maintenance.
Functional Capabilities
- Low-Friction Sliding Support: Self-lubricating slide bearings and Polypenco gliders enable smooth, maintenance-free tool frame movement, eliminating dry friction and binding during pipe handling.
- Stable Torque Transmission: Precision drive hubs, roller assemblies, and ball bearings transfer consistent torque for SW-10 spinning wrenches, ensuring accurate drill pipe makeup/breakout.
- Wear Resistance & Protection: AMPCO alloy bushings, wear plates, and glide pads absorb friction and impact, extending the service life of critical tool frame components.
- Reliable Power Transmission: Heavy-duty leaf chains and chain bolts secure hydraulic roughneck components, maintaining stable tension and alignment during operation.
- Precision Adjustment: 1mm/2mm/3mm shim sets allow fine-tuning of slide guide clearance, ensuring optimal tool frame alignment and operational accuracy.
- Safe Operational Control: Electrical components including push buttons, pulse encoders, and transmitters enable safe, precise control of tool frame movements.
Structural Design Features
- Exact MPT-200 OEM Fit: Precision-machined dimensions and OEM part number/position code matching ensure seamless replacement, cutting on-site installation time by up to 50%.
- Self-Lubricating Design: Specialized slide bearings and gliders eliminate routine lubrication, reducing maintenance labor and preventing contamination of drilling components.
- High-Wear Alloy Construction: AMPCO 18/45 bronze bushings and hardened steel bearings resist abrasion and impact, with a service life 30% longer than standard parts.
- Load-Bearing Durability: Heavy-duty leaf chains and reinforced components withstand high torque loads and vibration typical of drilling rig operations.
- Modular Repair Design: Individual wear parts, bearings, and gliders enable targeted replacements, minimizing part waste and lowering long-term maintenance costs.
Applicable Operating Conditions
These MPT-200 tool frame components are engineered to perform reliably in rigorous drilling scenarios, including:
- MPT-200 tool frames paired with Hydratong SW-10 spinning wrenches and hydraulic roughnecks
- Onshore/offshore drilling rigs for drill pipe makeup, breakout, and handling operations
- High-vibration, high-torque drilling environments with heavy daily operational cycles
- Continuous 24/7 rig operations requiring minimal maintenance and maximum uptime
- Routine tool frame maintenance, emergency field repairs, and full component overhauls
Maintenance & Service Recommendations
- Inspect Polypenco gliders, wear plates, and AMPCO bushings every 1000 operating hours for wear or damage; replace worn components to prevent friction-related failures.
- Check leaf chain tension and bolt tightness monthly, adjusting tension or replacing worn chains to maintain stable hydraulic roughneck alignment.
- Lubricate radial and angular contact ball bearings annually with high-temperature, heavy-duty grease to prevent premature bearing failure.
- Inspect grooved rollers and drive hubs for wear or deformation quarterly, replacing damaged parts to ensure consistent torque transmission.
- Test electrical control components (push buttons, encoders, transmitters) before each rig shift to verify proper functionality and safe operation.
- Use precision shims to adjust slide guide clearance as needed, maintaining optimal tool frame alignment and reducing unnecessary wear.
- We supply the following spare parts:
| SN | DISCRIPTION | PART # | POSITION |
| 1 | SLIDE BEARING, SELF LUBRICATING, W/FLANG | 10073 | M01 |
| 2 | HYDRAULIC ROUGHNECK; TOOL FRAME, FASTENING; LEAF CHAIN | XD110000954 | 2 |
| 3 | HYDRAULIC ROUGHNECK; TOOL FAME; POLYPENCO GLIDER | XD110000944 | 3 |
| 4 | BUSHING | 62564 | M03 |
| 5 | SPINNING WRENCH, SW-10; LOWER BEARING HOUSING;HYDRATONG MPT | XD110003392 | 3 |
| 6 | SPINNING WRENCH, SW-10; LOWER DRIVE HUB; HYDRATONG MPT | XD110003391 | 4 |
| 7 | SPINNING WRENCH, SW-10; UPPER DRIVE HUB; HYDRATONG MPT | XD110003390 | 5 |
| 8 | SPINNING WRENCH, SW-10; ROLLER WITH GROOVES (Ø180);DETAIL DRAWING | XD110003696 | 7 |
| 9 | SPINNING WRENCH, SW-10; UPPER BEARING HOUSING; HYDRATONG MPT | XD110003389 | 8 |
| 10 | RADIAL BALL BEARING | 37402 | M07 |
| 11 | ANGULAR CONTACT BALL BEARING | 28576 | M10 |
| 12 | EO 316 PLUG BSP 1.1/4-ED | 71986 | M12 |
| 13 | FLANGED BUSHING, ORKOT TLMM | 160210 | M24 |
| 14 | SPINNING WRENCH, SW-10;ROLLER WITH GROOVES (Ø180);DETAIL DRAWING | XD110003696 | 5 |
| 15 | RADIAL BALL BEARING | 37402 | M03 |
| 16 | ANGULAR CONTACT BALL BEARING | 28576 | M18 |
| 17 | EO 316 PLUG BSP 1.1/4-ED | 71986 | M20 |
| 18 | LOW TORQUE WRENCH;POLYPENCO GLIDER;HYDRAULIC ROUGHNECK | XD110001194 | 3 |
| 19 | DIES | 62348 | M02 |
| 20 | ELEVATED BACKUP TONG;POLYPENCO GLIDER;DETAIL DRAWING | XD110001547 | 2 |
| 21 | BUSHING, AMPCO 18;ITEM 99707;HYDRATONG MPT | XD110001703 | 3 |
| 22 | DIES | 62348 | M01 |
| 23 | ELEVATED BACKUP TONG;POLYPENCO GLIDER;DETAIL DRAWING | XD110001547 | 2 |
| 24 | BUSHING, AMPCO 18;ITEM 99707;HYDRATONG MPT | XD110001703 | 3 |
| 25 | DIES | 62348 | M01 |
| 26 | POLYPENCO GLIDE PAD;TRIPPLE GRIP TORQUE WRENCH – TW-3/30;HYDRATONG | XD110001207 | 13 |
| 27 | HYDRAULIC ROUGHNECK;LOW TORQUE WRENCH;PUR SPRING 95 SHORE | XD110001206 | 18 |
| 28 | WEARPLATE;TRIPLE GRIP TORQUE WRENCH;HYDRATONG | XD110001688 | 19 |
| 29 | TORQUE WRENCH;POLYPENCO, SLIDE PLATE;DETAIL DRAWING | XD110002132 | 22 |
| 30 | HYDRAULIC ROUGHNECK;ROTATION PLATE;DETAIL DRAWING | XD110004021 | 26 |
| 31 | Guide ring for Slide guide 60 deg;;DETAIL DRAWING | XD110003944 | 27 |
| 32 | OPTIONAL SHIM 3mm;SLIDEGUIDE;HYDRATONG | XD110003961 | 28 |
| 33 | OPTIONAL SHIM 1mm;SLIDEGUIDE;HYDRATONG | XD110004019 | A0866 |
| 34 | OPTIONAL SHIM 2mm;SLIDEGUIDE;HYDRATONG | XD110004018 | M01 |
| 35 | HYDRAULIC ROUGHNECK;DOLLY FRAME;LEAF CHAIN BOLT | XD110001620 | 4 |
| 36 | TORQUE WRENCH;STABILIZER PLUG;STABILIZER PLUG | XD110001555 | 5 |
| 37 | HYDRAULIC ROUGHNECK;TOOL FRAME, ADJ;LEAF CHAIN SUPPORT | XD110000952 | 7 |
| 38 | 1/2″ ELITE LEAF CHAIN | 198797 | M26 |
| 39 | DISC SPRING, SF-TAF | 95702 | M28 |
| 40 | POLYPENCO GLIDER; TOOL FRAME; HYDRATONG | XD110000943 | 2 |
| 41 | WIRE SHEAVE; FOR ELEVATION CENSOR;HYDRATONG MPT | XD110001789 | 3 |
| 42 | HYDRAULIC ROUGHNECK; TOOL FRAME, FASTENING;LEAF CHAIN | XD110000946 | 4 |
| 43 | FLANGED BUSHING, AMPCO 45 | 173556 | M05 |
| 44 | BEARING, AMPCO 45 | 173557 | M06 |
| 45 | MUSHROOM PUSH Red 1stk M25 {as per sample} | 50336 | |
| 46 | PROTECTION COVER f / MUSHROOM PUSH CEAG {as per sample} | 52375 | |
| 47 | PUSH BUTTOM INCL.LABELS ENT.1XM25 | 144884 | |
| 48 | PULSEENCODER Ex 1000ppr, IP66/67 INCR. {as per sample} | 192669 | |
| 49 | TRANSMITTER W/2M LINE MAIN CARRIAGE LENGTH | 80426 | |
| 50 | INITIATOR w/ PLUG | 158518 | |
| 51 | PLUG FOR INITIATOR w/25m CABLE | 80635 | |
| 52 | INITIATOR W/10M CABLE | 55346 |
Field Failure Repair Case Studies
Case 1: MPT-200 Tool Frame Sliding Binding
A MPT-200 tool frame experienced severe sliding binding due to worn self-lubricating slide bearings and Polypenco gliders. Replacing the 10073 flange bearings and XD110000944 gliders restored smooth, friction-free movement.
Case 2: SW-10 Spinning Wrench Torque Loss
Worn radial ball bearings (37402) and upper drive hub caused inconsistent torque output from the SW-10 spinning wrench. Installing new bearings and XD110003390 drive hub restored full torque transmission.
Case 3: Hydraulic Roughneck Chain Failure
A stretched leaf chain and loose chain bolts led to hydraulic roughneck misalignment. Fitting a new 198797 leaf chain and XD110001620 chain bolts resolved alignment issues and stabilized operation.
Frequently Asked Questions (FAQ)
| Question | Answer |
| Are these parts exclusively for the MPT-200 tool frame? | Yes, every component is precision-engineered for the MPT-200 tool frame, with full compatibility for Hydratong SW-10 spinning wrenches and matching hydraulic roughnecks. |
| Do these wear components require regular lubrication? | Self-lubricating slide bearings and Polypenco gliders need no routine lubrication; only standard ball bearings require annual lubrication for optimal performance. |
| What is the expected service life of these MPT-200 parts? | High-wear components like gliders and bushings last 3000+ operating hours, while bearings and chains have a 5000+ hour service life under normal drilling conditions. |
Procurement Guidance
For drilling rig maintenance teams and tool frame operators responsible for MPT-200 equipment performance, this catalog is your definitive sourcing solution for high-quality, OEM-matched spare parts. It provides full transparency on part descriptions, OEM part numbers, position codes, and compatibility details, serving as both a formal procurement compliance standard and a practical field troubleshooting reference for tool frame repairs and overhauls. Whether you need wear-resistant gliders and bearings for friction reduction, leaf chains and bushings for torque stability, die sets for pipe gripping, or electrical components for safe control, every part is engineered to resolve common MPT-200 failures and deliver consistent, reliable drill pipe handling performance. Submit your detailed inquiry with specific part numbers, required quantities, and position codes to secure precision-matched components tailored to your MPT-200 tool frame needs. Our technical team provides full compatibility verification, installation guidance, and wear life recommendations to streamline your procurement process and ensure efficient, trouble-free on-site installation.
