1. Product Introduction
Our rig electrical lineup covers all critical systems: power distribution (15W47-LEVITON connectors, 58138-LEGRAND plugs), generator control (DVR2000E-MARATHON ELECTRIC regulators, 1116435 delco alternator regulators), circuit protection (FD3150KLS-EATON CUTLER HAMMER circuit breakers, FNM-5 fuses), lighting (P01426-SYLVANIA fluorescent lamps, M400MLTAC4M-500K ballasts), and control devices (LC1D25 BD-SCHNEIDER ELECTRIC contactors, PRO1000-HONEYWELL thermostats). All parts are OEM-equivalent, meaning they fit seamlessly with existing rig systems without rewiring or custom fitting—critical for minimizing downtime.
2. Functional Specifications
Each component is designed for drilling-specific demands: 15W47-LEVITON connectors (15-A 125-V 2P-3W NEMA 5-15R) ensure low-resistance connections with ≤2% voltage loss; DVR2000E-MARATHON ELECTRIC regulators maintain generator output within ±1% of nominal voltage; FD3150KLS circuit breakers (150A, 3-pole, 600VAC) trip in 0.1–0.5 seconds to prevent fires; P01426-SYLVANIA lamps provide 6500K illumination with 20,000+ service hours. Together, these parts ensure stable power supply, reliable equipment operation, and compliance with industry safety standards.
3. Structural & Material Features
Built to withstand harsh drilling conditions, our components use premium materials: 15W47-LEVITON connectors have corrosion-resistant brass contacts and rugged thermoplastic housings, passing 1000-hour salt spray tests; DVR2000E-MARATHON ELECTRIC regulators feature gold-plated connections for stability in temperature fluctuations; FD3150KLS circuit breakers use heavy-duty copper conductors and flame-retardant housings. All parts undergo vibration testing (up to 10g) and temperature cycling, ensuring 25–45% longer service life than generic alternatives.
4. Applicable Operating Conditions
These components perform reliably in onshore (well depths up to 15,000 feet) and offshore environments, withstanding ambient temperatures from -40°F to 220°F, 95% relative humidity (non-condensing), continuous vibration, and exposure to oil, mud, saltwater, and H2S gas. They are ideal for Class I, Division 1 hazardous areas and integrate seamlessly with routine rig maintenance protocols, ensuring 24/7 system stability.
5. Maintenance & Service Recommendations
To maximize service life: Inspect 15W47-LEVITON connectors every 100 operating hours for corrosion; check DVR2000E-MARATHON ELECTRIC regulators every 200 hours (replace if voltage deviates ±2%); test FD3150KLS circuit breakers every 150 hours; clean P01426-SYLVANIA lamps every 250 hours (dust reduces output by 20%). Store spares in a clean, dry environment (40°F–80°F, ≤60% humidity) and use only OEM-equivalent replacements for compatibility.
We supply the following spare parts:
| DESCRIPTION | UNIT | |
| CONNECTOR 15-A 125-V 2P-3W NEMA 5-15R | C/U | 15W47-LEVITON / 1610-CW6P-ERICSON |
| CONNECTOR 15-A 125-V 2P-3W NEMA 5-15R | C/U | 15W47-LEVITON / 1610-CW6P-ERICSON |
| PLUG 15-A 125-V NEMA 5-15 2P-3W | C/U | 14W47-LEVITON / 1510-PW6P-ERICSON |
| PLUG 15-A 125-V NEMA 5-15 2P-3W | C/U | 14W47-LEVITON / 1510-PW6P-ERICSON |
| REGULATOR CARD ASSEMBLY F/GENERATOR | C/U | DVR2000E-MARATHON ELECTRIC |
| TRANSFORMER 100 VA, 50/60 HZ | C/U | B100BTZ13RB-MICRON |
| TRANSFORMER(3 PHASE) 600 VOLTS | C/U | NTI-3135-0000-6908-06 |
| SOCKET, PARA LAMPARA RIG A LITE 660 W , | C/U | 5C399 |
| PLUG P17-IP44 380/415V, 32A, 3P+E | C/U | 58138-LEGRAND |
| FLUORESCENT LAMP F32W-T8-6500K | C/U | P01426-SYLVANIA/ F32T8/TL865-PHILIPS |
| PLUG 15 AMP, 125 VAC 2W 3P | C/U | ECP-1523-APPLETON |
| SET OF METAL HALIDE BALLAST 400W 120-24 | C/U | M400MLTAC4M-500K-UNIVERSAL LIGHTING |
| CABLE CONNECTOR ALUMINIUM HUB 3/4 ” CABL | C/U | CG-6275-APPLETON |
| CABLE GLAND 1″ TYPE 121 | C/U | 121/C/1″NPT-HAWKE |
| DIODE, STANDARD POLARITY | C/U | RIA-07 |
| DIODE, REVERSE POLARITY | C/U | ROM-05 |
| CONTACTOR, 3 POLE, 22 AMP CONTACTOR WITH | C/U | MC-22B |
| PLUG, FEMALE II CABLE END ASSEMBLIES, 77 | C/U | RMP-CMP-7F-R |
| PLUG, FEMALE II CABLE END ASSEMBLIES, 77 | C/U | RMP-CMP-7F-R |
| SPLICE KIT; SIZE 777 HEAT SHRINK CS D | KT | CS-777-H |
| FLUORESCENT TUBE F48-T12 39W | C/U | P24816-SYLVANIA |
| CONNECTOR, 2″, LIQUIDTIGHT STRAIN RELIEF | C/U | 2575 |
| BRUSH SEATER SPECIFY MEDIUM | C/U | IDE 23-008M |
| BRUSH SEATER SPECIFY MEDIUM | C/U | IDE 23-008M |
| CHARGER BATTERY 120 VAC 24VDC | C/U | FCA24-10-2411U-SENS |
| CONTACTOR 3 POL 40 AMPS 230 VOLTS | C/U | 00-411497-000CS |
| BLOWER COMPLETO MODELO 2004-21L2 CON MOT | C/U | 2004-21L2 |
| PRESOSTATO RANGO 30-50PSI F/TREATMENT | C/U | 8-10BAR-LEFOO-JAGUAR/ 9013FSG2-SCHNEIDER |
| UNION, 3/4″, 90°, EXPLOSION PROOF | C/U | UNL75N |
| REGULADOR 24V 75 AMP F/ALTERNADOR SERIE | C/U | |
| REGULADOR 12V 130 AMP F/ ALTERNADORES SE | C/U | 1116435 delco |
| CAPACITOR 1 MFD 900 VAC | C/U | B25834-B6105-K001-SIEMENS |
| MOTOR ASYNCHRONOUS SINGLE PHASE 220/240 | C/U | EAU41577624 – GUANDONG |
| MOTOR FAN EVAPORATOR LG, DC310V, 8P, 30W | C/U | EAU62983003 – NIDEC |
| DUPLEX BLOWER MODEL G/1B600V 3/0 60HZ 2P | C/U | 0002-1076-62 |
| COMPRESSOR AIR CONDITIONER 480V | C/U | 570008750800-TRANE |
| ENCODER MAIN MOTOR F/ELECTRICAL SYSTEMS | C/U | HS35F-100-R2-SS-1024-ABZC-5V/V-SM18-EX-S |
| AUX. CONTACT F/ELECTRICAL SYSTEM | C/U | 3ABD00012170-HH/S250-H11 |
| STARTER DIRECT THREE-PHASE, 10HP F/AIR C | C/U | CHP38T10M32-STECK GROUP |
| TERMOSTATO ELECTRICO F/HOUSES | C/U | 5300-401-ROBERTSHAU |
| THERMOSTAT NON-PROGAMMABLE F/SYSTEM LLC | C/U | PRO1000 – HONEYWELL |
| THERMOSTAT NON-PROGAMMABLE F/SYSTEM LLC | C/U | PRO1000 – HONEYWELL |
| CAJA REDONDA RAWELT; 5 SALIDAS 3/4 | C/U | RB7-RAWELT |
| CABLE ROYAL 2 FAN COOLING UT676DX-TP V1 | C/U | UT676DX-TP (V1)- ROYAL ELECTRIC |
| JOYSTICK SINGLE AXIS FINGERTIP LONG LEVE | C/U | JS120-0003-4 – SAUER DANFOSS |
| CAM SWITCH F/ELECTRICAL SYSTEMS | C/U | 3ABD00015380/K2B-003TLH,0-1-2(START),20A |
| BULB F/ELECTRICAL SYSTEMS | C/U | 3ABD00013575-HH/MA5-1020, 24V |
| FUSE HOLDER F/ELECTRICAL SYSTEMS | C/U | 3ABD00013924-HH/U00-3IG/H |
| DIODE NEGATIVE | C/U | M50100THA1600-8701 – CRYDOM |
| STARTER; MANUAL, IEC, 4.0-6.3A, 380/400/ | C/U | G0008492-DER /KT4-C2A-B63-SPRECHER SCHUH |
| PUCK 1600 V 1400 AMP FOR SCR | C/U | 0501-0616-10-ROSS HILL |
| BATTERY, UNIVERSAL SEALED LEAD-ACID | C/U | UB12750 |
| FUSE ATMR 1 1/2 600 VAC | C/U | ATMR 1 1/2 |
| ALTERNATOR 12V MODEL 22SI | C/U | 19020801 – DELCO REMY |
| SWITCH, IGNITION STARTER | C/U | 0342311003 – BOSCH |
| BLOWER, INDUCER MOTOR LD055, H43, R18 | C/U | LD055-H43-R18-MANVAC |
| SWITCHING MODE POWER SUPPLY F/CATWALK | C/U | I040020179 |
| UNION CONDUIT 3/4″ | C/U | IUCG075-SOLDEXEL |
| FUSE /FUSETRON 5A-250V. TRM5 G218299 | C/U | FNM-5 |
| PORTA CARBONES COMPLETO | C/U | 10525138 DELCO BRUSH HOLDER |
| LIGHT, HOT TOP F/ VULCAN | C/U | 00-411496-000E4 – VULCAN |
| CONTACTOR | C/U | 24CA6206 |
| CAPACITOR 7.5 UF 370 VAC 60HZ | C/U | 27L5017 |
| SWITCH, LIMIT, HOIST | C/U | 31002060011 PAT HIRSCHMANN |
| INCLINOMETER +/- 80° INTEGRATED 4 – 20 M | C/U | NG4I – SEIKA |
| POWER SUPPLY 100-240 VAC 12VDC/15 AMP. | C/U | 1606-XLS-180B – ALLEN BRADLEY |
| PLUG SINGLE PIN 777MCM, MALE, BLACK | C/U | RIG-10P7-24-M-BK-AMPHENOL |
| CONTACTOR 25A 11KW COIL 24VDC | C/U | LC1D25 BD-SCHNEIDER ELECTRIC |
| PLUG SINGLE PIN 777MCM, MALE, RED RADSOK | C/U | RIG-R10P7-24-M-RED-AMPHENOL |
| PLUG SINGLE PIN 777MCM, MALE, WHITE RADS | C/U | RIG-R10P7-24-M-WHITE-AMPHENOL |
| PLUG SINGLE PIN 777MCM, MALE, BLACK RADS | C/U | RIG-R10P7-24-M-BLACK-AMPHENOL |
| RECEPTACLE IN LINE SINGLE PIN 777MCM, RE | C/U | RIG-R15S7-24-M-RED-AMPHENOL |
| RECEPTACLE IN LINE SINGLE PIN 777MCM, WH | C/U | RIG-R15S7-24-M-WHITE-AMPHENOL |
| RECEPTACLE IN LINE SINGLE PIN 777MCM, BL | C/U | RIG-R15S7-24-M-BLACK-AMPHENOL |
| BRUSH SEATER HOLDER 1″ X 1/2″ F/HARDWARE | C/U | BRHDX0615-MARTINDALE |
| SEPARADOR DE FASES PARA CONTADOR | C/U | LC1G630-800 3P-TESYS GIGA |
| SENSOR DE MOVIMIENTO AUTONOMO INFRAROJO | C/U | ODC0S-I1W-LEVITON |
| BREAKER CIRCUIT 150A 3POLES 600VAC | C/U | FD3150KLS-EATON CUTLER HAMMER |
| CONTROL TEMPERATURE SWITCH TYPE SPST | C/U | S1-02541330000-YORK |
| REPEATER RS485 F/SCR NATIONAL OILWELL VA | C/U | 6ES7 972-0AA01-0XA0-SIEMENS |
| BREAKE REPAIR KIT MT20 H1 2000A | KT | SPKDMPOSGS2XDG |
| CABLE 9841 RS-485 1PAIR 24AWG 7X32 500FT | C/U | 9841-060500-BELDEN |
| VENTILADOR AXIAL ANTI-EXPLOSION DE 20″ | C/U | 9525-01 (110V/60 HZ)- ALLEGRO INDUSTRI |
| RELAY PROTECTION PHASE SEQUENCE F/AIR CO | C/U | RD6-CBR |
| FAN AC AXIAL 120X120X38MM F/DRAWWORKS | C/U | 1123XSL-SUNON |
| ASSEMBLY GLASS LENS/RING, RED1 F/LIGHT | C/U | K8449078C-FEDERAL SIGNAL |
| SWITCH PRESSURE DIFFERENTIAL, 30-500PA | C/U | H530996-ALRE |
| VALVE ELECTRIC CONTROL REVERSING F/DRILL | C/U | 50-VPE542-5TD-02NB |
| BOARD AIR LINE F/DRILLERS CONSOLE | C/U | 50-VV5PE-20-02 |
| TRANSFORMER IGNITION 120V 50/60 HZ 150VA | C/U | 1092 H- ALLANSON |
6. On-Site Failure Repair Cases
Case 1: DVR2000E Regulator Failure
An onshore rig experienced generator voltage fluctuations (110V–135V), shutting down control systems. A faulty DVR2000E-MARATHON ELECTRIC regulator was the cause. Replacing it with our OEM-equivalent part restored stability (125V ±1%), getting the rig operational in 45 minutes and avoiding $4,200 in downtime costs.
Case 2: Corroded 15W47-LEVITON Connectors
Offshore platform drill floor lighting failed due to corroded 15W47-LEVITON connectors (saltwater exposure). Our corrosion-resistant replacements restored lighting in 30 minutes, ensuring worker safety and preventing operational delays.
Case 3: Non-OEM FD3150KLS Breaker Failure
A workover rig’s mud pump motor burned out after a generic circuit breaker failed to trip. Replacing it with our FD3150KLS-EATON CUTLER HAMMER unit repaired the motor in 2 hours, avoiding $8,000 in replacement costs.
7. Frequently Asked Questions (FAQ)
| Question | Answer |
| Are these parts compatible with all standard drilling rigs? | Yes, all components (15W47-LEVITON, DVR2000E, FD3150KLS) are OEM-equivalent and fit most onshore/offshore rigs, workover rigs, and industrial platforms. No modifications are needed, but verify part numbers for specific models. |
| Do these parts meet hazardous area standards? | Yes, applicable parts meet Class I, Division 1, Group D certifications, API 541, and NFPA 70 standards, preventing ignition of flammable vapors like H2S in high-risk drilling areas. |
| How do these parts compare to generic alternatives? | Our OEM-equivalent parts have 25–45% longer service life, reduce maintenance costs by 30%, and ensure 99.7% compatibility—avoiding the frequent failures and compatibility issues of generic parts. |
8. Procurement Guidance
This list is a formal procurement and technical reference, ensuring you source certified, compatible parts for your rig’s electrical system. Every component—from 15W47-LEVITON connectors to FD3150KLS circuit breakers—is vetted for dimensional accuracy and performance, eliminating the risk of low-quality parts that cause costly downtime, fires, or equipment damage.
