Sandvik D50KS Drilling Rig OEM-Equivalent Spare Parts

1. Product Introduction

This comprehensive parts package features fully interchangeable spare components for the Sandvik D50KS rig, covering critical subsystems: rotator guide sliding plates, hydraulic pumps/motors, high-pressure hoses, filtration elements, bearings, seals, electrical sensors, belts, and specialized repair kits. Sourced from certified premium manufacturers (Sandvik, Parker Europe, SKF, BOSCH, MULCO), these parts meet ISO 9001 quality certifications, with key part numbers cross-referenced to original Sandvik part numbers for seamless inventory matching and ordering accuracy.

2. Functional Description

Each part performs a mission-critical role in maintaining rig efficiency and drilling productivity: high-pressure hydraulic hoses (rated up to 5000 PSI) deliver consistent fluid flow to propulsion/rotation motors; precision SKF bearings reduce friction and support radial loads up to 800 kN; wear-resistant rotator sliding plates minimize abrasion during drilling rotation; multi-grade filters protect hydraulic/fuel systems from contamination; temperature/pressure sensors (5 bar, 15 bar, 25 bar) monitor rig health; and heavy-duty belts/bearings sustain continuous drilling operation. Hydraulic pump seals and repair kits prevent fluid leaks, while electrical components ensure reliable control system operation.

3. Structural & Material Highlights

• Wear Components: Hardened steel rotator guide sliding plates (HRC 52-55 hardness) for abrasion resistance, rated for 1,200+ drilling hours of continuous use.
• Hydraulic System Parts: Braided steel high-pressure hoses with oil-resistant nitrile rubber inner liners; Parker Denison hydraulic pumps with 240 cm³/rev displacement and 350 bar continuous pressure rating.
• Filtration Elements: High-efficiency Hi-Fi Filter media with 10-micron particle capture, extending hydraulic oil and engine life by 40%.
• Electrical & Sensor Parts: 24V solenoids, BOSCH temperature/pressure sensors with IP67 waterproof rating, and robust battery switches for harsh mine conditions.
• Sealing & Fastening Parts: High-temperature nitrile seals (withstanding up to 600°C for exhaust components) and precision bronze sliding bushings for low-friction movement.

4. Applicable Operating Conditions

These Sandvik D50KS parts are validated for extreme heavy-duty drilling scenarios, including:

• Open-pit mining and quarry blasthole drilling (hard rock, abrasive rock formations)
• Continuous-duty operation with high-vibration, dust, and moisture exposure
• Hydraulic system operation up to 5000 PSI and temperature ranges from -20°C to 90°C
• Exhaust system components rated for up to 600°C high-temperature resistance
• Preventive maintenance and emergency repairs for Sandvik D50KS crawler drilling rigs

5. Proactive Maintenance & Troubleshooting Recommendations

Maximize component lifespan and reduce downtime with these field-proven guidelines:

• Replace hydraulic/fuel filters every 500 drilling hours to prevent contamination and pump wear; use OEM-equivalent Hi-Fi Filter elements for optimal filtration.
• Inspect high-pressure hydraulic hoses quarterly for cracks, abrasion, or leaks; replace worn hoses before failure to avoid catastrophic fluid loss.
• Lubricate bearings and sliding plates every 300 hours with high-temperature lithium grease; replace SKF bearings at 8,000-hour intervals.
• Test pressure/temperature sensors and solenoids monthly; calibrate or replace faulty components to maintain accurate rig monitoring.
• Replace drive belts (generator, AC) before summer operation to prevent breakage during high-load, high-temperature drilling.

We supply the following spare parts:

	Spare parts and components for drilling rigs Sandvik D50KS
1	Rotator guide sliding plates	006985-002		SANDVIK	pcs
2	Rotator guide sliding plates	013732-006		SANDVIK	pcs
3	Generator belt	024340-051	Wedge-toothed, L 1689	MULCO	pcs
4	Cardan shaft crosspiece	001022-053		SANDVIK	pcs
5	ICE exhaust clamp	003056-009	Clamp, up to 600˚С	SANDVIK	pcs
6	ICE exhaust corrugation	034884-004	Corrugation, up to 600˚С	SANDVIK	pcs
7	Air hose to the rotator	009868-121	D 50 L 9200 1000psi	Parker Europe	pcs
8	Lower key hydraulic cylinder angular coupling	016308-002		Parker Europe	pcs
9	Seals for the retaining key hydraulic cylinder	020054-051		Parker Europe	pcs
10	Rotator gearbox breather valve	001670-002	5 bar	Parker Europe	pcs
11	Rotation hydraulic motor shaft	002746-082		SANDVIK	pcs
12	Rotation hydraulic motor seal	002746-087		Parker Europe	pcs
13	Propellent hydraulic pump seals	001330-416		Parker Europe	pcs
14	Propellent hydraulic pump shaft	001330-055		SANDVIK	pcs
15	Hydraulic hoses to the rotation hydraulic motor (on the mast)	001763-138	38SFS63,5 d1 1/4 SFS63,5, 5000psi, 9100	Parker Europe	pcs
16	Hydraulic hoses to the rotation hydraulic motor (on the mast)	006677-030	38SFS63,5 d1 1/4 1,1/16ˮ-12, 5000psi, 9000	Parker Europe	pcs
17	Air conditioner belt (replace before the summer season)	001185-005	L 1180/5	MULCO	pcs
18	Air conditioner and heater motor brushes	008692-098		BOSCH	pcs
19	Shock-absorbing bushing for the rotator hose bracket	008718-005		SANDVIK	pcs
20	Propellent pump gearbox	001003-014		SANDVIK	pcs
21	Chain tensioner pin	015864-003		SANDVIK	pcs
22	Planetary gear	001004-091		SANDVIK	pcs
23	Mast stop hydraulic cylinder	005953-003		Parker Europe	pcs
24	Die	004490-005		SANDVIK	pcs
25	Die	004490-004		SANDVIK	pcs
26	Chain lock	022738-005		SANDVIK	pcs
27	Chain lock	022739-002		SANDVIK	pcs
28	Propeller shaft	001022-001		SANDVIK	pcs
29	Propeller shaft	001022-009		SANDVIK	pcs
30	Bearing	001019-001		SKF	pcs
31	Bearing	001019-002		SKF	pcs
32	Bearing	003837-056	D=100, d=55	SKF	pcs
33	Relay	015120-001		BOSCH	pcs
34	Propeller shaft bolt	001555-103		SANDVIK	pcs
35	Stop cylinder repair kit	005953-089		Parker Europe	pcs
36	Adjuster repair kit	001068-065		Parker Europe	pcs
37	Coupling sleeve	001159-007	D=120	SANDVIK	pcs
38	Bushing	001244-001	Bronze sliding bushing BNZF692835220 (PBF1202820)	SANDVIK	pcs
39	Solenoid	002006-003	24V	SANDVIK	pcs
40	Connector	003983-084	D1= 45; D2= 40	SANDVIK	pcs
41	Thermostat	005167-003	90˚С	SANDVIK	pcs
42	Stop cylinder repair kit	005953-090		Parker Europe	pcs
43	Brushes	008692-098		BOSCH	pcs
44	Solenoid	017503-002	24V	Parker Europe	pcs
45	Valve	018171-002		SANDVIK	pcs
46	Valve	018591-001		SANDVIK	pcs
47	Convector 24/12	021248-001	24V to 12V	BOSCH	pcs
48	Lower key hydraulic cylinder	028806-001		Parker Europe	pcs
49	Pressure sensor	002829-007	5 bar	SANDVIK	pcs
50	Pressure sensor	013051-006	25 bar	SANDVIK	pcs
51	Pressure sensor	013051-005	5 bar	SANDVIK	pcs
52	Clamp	001098-001	D=125	SANDVIK	pcs
53	Breather	015279-051	3 bar	SANDVIK	pcs
54	Linear filter	007022-001	D7: 1’3/8-12UNF	Hi-Fi Filter	pcs
55	Jack sensor	022416-003		SANDVIK	pcs
56	Clamp	017789-001		SANDVIK	pcs
57	Temperature sensor	002828-004		BOSCH	pcs
58	Coupling	001003-085		SANDVIK	pcs
59	Cartridge	003688-002		SANDVIK	pcs
60	Pin	005953-076	D1= 25; D2= 20	SANDVIK	pcs
61	Valve	009679-002		BOSCH	pcs
62	Temp sensor	022893-001		SANDVIK	pcs
63	Pressure sensor	001709-002	15 bar	SANDVIK	pcs
64	Valve	003437-001	5 bar	SANDVIK	pcs
65	Joystick	014441-019		BOSCH	pcs
66	Hydraulic cylinder piston tip	007875-009		SANDVIK	pcs
67	Repair kit	020067-051		Parker Europe	pcs
68	Repair kit	008172-058		Parker Europe	pcs
69	Repair kit	020055-051		Parker Europe	pcs
70	Belt	019851-051	L 1689	MULCO	pcs
71	Seals	001330-223		Parker Europe	pcs
72	Seals	019146-062		Parker Europe	pcs
73	Battery switch	021256-001		BOSCH	pcs
74	Seals	001110-008		Parker Europe	pcs
75	Seals	001110-007		Parker Europe	pcs
76	Seals	001330-416		Parker Europe	pcs
77	Chain link	022738-004		SANDVIK	pcs
78	Shaft seal	001329-153		Parker Europe	pcs
79	Air conditioner hose assembly	019377-022	3/4ˮ-16 d1/2 3/4ˮ-16, 1000psi, 8000	Parker Europe	pcs
80	Air conditioner hose assembly	019377-021	3/4ˮ-16 d1/2 3/4ˮ-16, 1000psi, 9000	Parker Europe	pcs
81	High pressure hose	007725-936	50SFS79,6 d1 1/2 SFS79,6, 1500psi, 3000	Parker Europe	pcs
82	High pressure hose	007725-432	50SFS79,6 d1 1/2 SFS79,6(90), 1500psi, 3000	Parker Europe	pcs
83	High pressure hose	001763-032	1,5/16ˮ-12 d1 1/4 15,16ˮ, 5000psi, 1500	Parker Europe	pcs
84	High pressure hose	001763-040	1,5/16ˮ-12 d1 1/4 15,16ˮ, 5000psi, 2000	Parker Europe	pcs
85	High pressure hose	001763-025	38SFS63,5 d1 1/2 1,5/8ˮ-12, 5000psi, 2000	Parker Europe	pcs
86	High pressure hose	037295-007	SFS100 d4 SFS100, 1500psi, 1200	Parker Europe	pcs
87	High pressure hose to the travel motor	001763-231	38SFS63,5 d1 1/2 25SFS47,6, 1500psi, 1200	Parker Europe	pcs
88	High pressure hose to the travel motor	001763-232	38SFS63,5 d1 1/2 25SFS47,6, 1500psi, 1300	Parker Europe	pcs
89	High pressure hose for the return line of the travel motor	BH00012344	1,1/16ˮ-12 d3/4 1,1/16ˮ, 5000psi, 2500	Parker Europe	pcs
90	High pressure hose from the brake chamber	BH00012345	7/16ˮ-20 d1/4 7/16ˮ, 5000psi, 4500	Parker Europe	pcs
91	High pressure hose for the return line to the travel valve	001337-456	3/4ˮ-16 d1-/2 3/4ˮ, 5000psi, 500	Parker Europe	pcs
92	High pressure hose from the radiator to the thermostat	007725-888	38SFS63,5 d1 1/2 SFS63,5(90),1000psi, 2200	Parker Europe	pcs
93	High pressure hose from the radiator to the thermostat	007725-889	38SFS63,5 d1 1/2 SFS63,5,1000psi, 1200	Parker Europe	pcs
94	High pressure hose from the receiver to the compressor	007725-963	50SFS79,6 d1 1/2 38SFS63,5,1000psi, 3000	Parker Europe	pcs
95	High pressure hose from the compressor to the filter	007725-987	38SFS63,5 d1 1/2 SFS63,5(90),1000psi, 2500	Parker Europe	pcs
96	High pressure hose from the fan pump to the pipes	007725-777	38SFS63,5 d1 1/2 SFS63,5(90),1000psi, 3000	Parker Europe	pcs
97	High pressure hose from the fan pump to the pipes	001763-237	25SFS47,6 d1 1/4 38SFS63,5, 5000psi, 1200	Parker Europe	pcs
98	High pressure hose from the fan pump feed	001763-238	25SFS47,6 d1 1/4 1,5/16ˮ-12, 5000psi, 3100	Parker Europe	pcs
99	High pressure hose	001337-573	1,5/16ˮ-12 d1 1/4 1,5/16ˮ, 5000psi, 3000	Parker Europe	pcs
100	High pressure hose	BH00022513	1,5/16ˮ-12 d1 1/4 1,5/16ˮ, 5000psi, 4000	Parker Europe	pcs
101	High pressure hose	007725-554	50SFS79,6(90) d1 1/2 SFS79,6, 1000psi, 1000	Parker Europe	pcs
102	High pressure hose	009868-120	D 50 L 6000 1000psi	Parker Europe	pcs
103	High pressure hose	009868-123	D 50 L 8000 1000psi	Parker Europe	pcs
104	High pressure hose	001337-271	3/4ˮ-16 d1/2 3/4ˮ, 5000psi, 3500	Parker Europe	pcs
105	High pressure hose	001337-048	3/4ˮ-16 d1/2 3/4ˮ, 5000psi, 3600	Parker Europe	pcs
106	High pressure hose	001337-914	3/4ˮ-16(90) d1/2 3/4ˮ, 5000psi, 1500	Parker Europe	pcs
107	High pressure hose	001337-915	3/4ˮ-16(45) d1/2 3/4ˮ, 5000psi, 1500	Parker Europe	pcs
108	High pressure hose	006677-519	3/4ˮ-16 d1/2 BS24, 5000psi, 2500	Parker Europe	pcs
109	High pressure hose	001763-139	38SFS63,5 d1 1/4 SFS63,5, 5000psi, 9200	Parker Europe	pcs
110	High pressure hose	001763-030	1,5/16ˮ-12 d1 1,5/16ˮ, 5000psi, 1000	Parker Europe	pcs
111	High pressure hose	001763-029	1,5/16ˮ-12 d1 1,5/16ˮ, 5000psi, 1100	Parker Europe	pcs
112	High pressure hose	001763-276	25SFS47,6 d1 1/4 SFS47,6, 5000psi, 2300	Parker Europe	pcs
113	High pressure hose 2LT-10 FJ10 L3300	Rammer	2LT-10 FJ10 L3300	Parker Europe	pcs
114	High pressure hose 2LT-10 FJ10 L2900	Rammer	2LT-10 FJ10 L2900	Parker Europe	pcs
115	High pressure hose 2LT-10 FJ10 L2100	Rammer	2LT-10 FJ10 L2100	Parker Europe	pcs
116	High pressure hose 4LT-12 FJ12 FJ16 L6000	Rammer	4LT-12 FJ12 FJ16 L6000	Parker Europe	pcs
117	High pressure hose 2LT-16 FJ16 L5600	Rammer	2LT-16 FJ16 L5600	Parker Europe	pcs
118	High pressure hose 2LT-10 FJ10 L6000	Rammer	2LT-10 FJ10 L6000	Parker Europe	pcs
119	High pressure hose CS14 2LT-10 FJ10 L5500	Rammer	2LT-10 FJ10 L5500	Parker Europe	pcs
120	High pressure hose 2LT-16 FJ16 L6000	Rammer	2LT-16 FJ16 L6000	Parker Europe	pcs
121	High pressure hose 2LT-6 FJ8 L800	Rammer	2LT-6 FJ8 L800	Parker Europe	pcs
122	High pressure hose 2LT-6 FJ8 L1000	Rammer	2LT-6 FJ8 L1000	Parker Europe	pcs
123	Oil filter	033329-053	D7: 1’3/8-12UNF	Hi-Fi Filter	pcs
124	Fine fuel filter	019854-051	D7: 1′-14UNF	Hi-Fi Filter	pcs
125	Compressor oil filter	007947-070	D7: 1’1/2-16UNF	Hi-Fi Filter	pcs
126	Servo feed filter	002301-070	H1:200mm. D1:45.5mm. D2:19.5mm	Hi-Fi Filter	pcs
127	Primary air filter	021237-052	(H1): 508 mm. (D1): 178 mm. D2: 172 mm. D3: 145 mm.	Hi-Fi Filter	pcs
128	Primary fuel filter	BG01102058	D7: M12X1,5	Hi-Fi Filter	pcs
129	Hydraulic tank return filter	004724-072	D7: 1’1/2-14UNF	Hi-Fi Filter	pcs
130	Air-oil separator filter element	005099-001		Hi-Fi Filter	pcs
131	Secondary air filter	021237-051	H: 631 mm. D1: 358 mm. D2: 232 mm.	Hi-Fi Filter	pcs
132	Reducer for driving working hydraulic pumps	004167-005		SANDVIK	pcs
133	Propulsion pump	002764-029	Displacement [cm3/rev]- 240; Pressure: max. short-term 1) [bar]- 420; max. continuous [bar]- 350;	Parker Denison	pcs
134	Feed pump	002764-013	Displacement [cm3/rev]- 150; Pressure: max. short-term 1) [bar]- 420; max. continuous [bar]- 350;	Parker Denison	pcs
135	Rotation pump	002764-011	Displacement [cm3/rev]- 240; Pressure: max. short-term 1) [bar]- 420; max. continuous [bar]- 350;	Parker Denison	pcs
136	Auxiliary pump	021434-007	Displacement [cm3/rev]- 60; Pressure: max. short-term 1) [bar]- 480; max. continuous [bar]- 420;	Parker Denison	pcs
137	Heater motor	008692-057	M/Nm- 6.8; I/A- 6.3; N/rpm- 3000	BOSCH	pcs

Field Fault Repair Case Studies (Real-World Drilling Scenarios)

Case 1: Hydraulic Hose Leakage & Drilling Power Loss

A quarry-based Sandvik D50KS rig experienced sudden hydraulic fluid leakage and reduced rotation power, traced to a cracked 5000 PSI mast hydraulic hose. Replacing the damaged hose (001763-138) with a premium Parker Europe assembly restored full hydraulic pressure, eliminated leaks, and resumed drilling operations within 60 minutes.

Case 2: Premature Rotator Sliding Plate Wear

An open-pit mine D50KS rig showed excessive vibration and inconsistent rotation speed, caused by worn rotator guide sliding plates. Installing new hardened Sandvik sliding plates (006985-002, 013732-006) reduced friction, stabilized drilling rotation, and extended the rotator service life by 50%.

Case 3: Hydraulic Pump Seal Failure & Oil Leakage

A Sandvik D50KS rig suffered persistent propulsion pump oil leaks, leading to low hydraulic pressure. Replacing the worn pump seals (001330-416) with a Parker Europe repair kit stopped leakage, restored pump pressure, and avoided costly full pump replacement.

Frequently Asked Questions (FAQ)

Question	Answer
Are these parts fully compatible with the Sandvik D50KS drilling rig?	Yes, all parts are engineered to match Sandvik OEM dimensions, material specs, and performance ratings, ensuring direct drop-in fit for the D50KS crawler drill.
What pressure rating do the hydraulic hoses have?	High-pressure hydraulic hoses are rated for 1000 PSI to 5000 PSI, matching the D50KS rig’s hydraulic system requirements for propulsion, rotation, and feed functions.
How do I cross-reference these parts to original Sandvik part numbers?	Each part lists the official Sandvik OEM part number (e.g., 006985-002, 001022-053) for direct inventory matching and accurate ordering.

Procurement Guidance & Supply Value

Secure these high-quality Sandvik D50KS drilling rig parts to build a reliable maintenance inventory, minimize costly drilling downtime, and maintain peak rig performance. Each component is manufactured to deliver OEM-level durability, fit, and reliability, making this lineup the ideal choice for routine stock replenishment, emergency field repairs, and full rig overhauls. With precise cross-referencing, premium materials, and industry-grade performance, these parts reduce long-term maintenance costs and keep your Sandvik D50KS rig operating efficiently in harsh mining and quarry conditions. Reach out to finalize your customized parts order and establish a consistent, reliable supply chain for your drilling rig maintenance needs.
