1. Core Overview & Target Application
Equipment Compatibility: This full lineup of spare parts is precision engineered exclusively for the JWS400 drilling pump, a heavy-duty reciprocating mud pump widely deployed in land-based oil and gas drilling, workover operations, and geothermal drilling projects. Every component is manufactured to match OEM dimensional tolerances, material specifications, and performance benchmarks, ensuring full interchangeability with factory-installed parts and compliance with API 7K standards for drilling pump equipment.
2. Product Introduction
This curated inventory of JWS400 drilling pump spare parts includes 51 critical components covering power transmission systems, pressure monitoring devices, sealing solutions, lubrication parts, structural assemblies, and fluid control components. Key items include OEM-grade crankshafts, connecting rod bearings, cardan shafts, crosshead assemblies, precision pressure gauges (0–6000 PSI rating), lubrication pumps, repair kits, high-pressure hoses, and valve inserts. Each part undergoes strict material testing and performance verification, with load-bearing components rated for continuous high-torque operation and pressure parts certified to withstand maximum operating pressures without failure, matching or exceeding OEM service life standards.
3. Functional Advantages
- Zero Compatibility Risk: Direct drop-in replacement for OEM JWS400 parts, eliminating modification time and assembly errors, cutting installation downtime by up to 45% compared to generic aftermarket parts.
- Extended Service Life: High-grade alloy steel bearings, hardened crankshafts, and wear-resistant blanks reduce friction and wear, extending component replacement cycles by 30% and lowering recurring maintenance costs.
- Accurate Pressure Monitoring: Calibrated pressure gauges with ±1% full-scale accuracy provide real-time mud pressure readings, enabling operators to detect pressure anomalies and prevent pump overload failures.
- Reliable Sealing & Lubrication: Premium SKF seals, high-performance lubrication pumps, and specialized repair kits prevent fluid leakage and ensure consistent lubrication, reducing bearing and crankshaft failures by 50%.
4. Structural & Material Features
Every JWS400 drilling pump spare part is constructed with industrial-grade materials tailored to harsh drilling environments, featuring industry-leading design attributes:
- Power Transmission Components: Crankshafts and connecting rods use forged alloy steel with precision heat treatment (HRC 52–58 hardness), delivering exceptional fatigue resistance for high-load reciprocating operation.
- Bearing & Sealing Parts: SKF precision bearings and high-performance seals (Ecorubber, Ecopur, Ecoflon) resist mud abrasion, oil corrosion, and temperature fluctuations (-25°C to 90°C), maintaining integrity in harsh drilling conditions.
- Pressure Components: Stainless steel pressure gauge internals and high-pressure Parker Push-Lok hoses (rated for 160–3000 PSI) ensure stable pressure transmission and accurate monitoring without bursting or clogging.
- Wear & Blank Parts: Specialized polymer and rubber blanks with high compression resistance absorb vibration and reduce noise, protecting internal pump components from impact damage.
5. Applicable Operating Conditions
These JWS400 drilling pump spare parts are engineered to perform reliably in demanding drilling scenarios, including:
- Onshore oil and gas drilling rigs equipped with JWS400 reciprocating mud pumps
- Workover and well servicing operations with continuous mud circulation demands
- Geothermal drilling and directional drilling projects with high mud pressure requirements
- High-dust, high-vibration drilling sites with abrasive drilling mud conditions
- Routine maintenance and emergency repair scenarios for JWS400 pump units
6. Maintenance & Troubleshooting Recommendations
To maximize JWS400 drilling pump uptime and spare part lifespan, follow these industry-standard maintenance protocols aligned with API 7K guidelines:
- Preventive Replacement Schedule: Inspect bearings, seals, and blanks every 1000 operating hours; replace worn connecting rod bearings, pressure gauges, and filter elements every 2000 hours to prevent catastrophic failure.
- Lubrication System Maintenance: Service lubrication pumps and replace filter elements every 500 hours, using recommended lubricants to ensure consistent oil flow to power transmission components.
- Pressure System Checks: Calibrate pressure gauges quarterly and inspect high-pressure hoses for cracks or wear; replace damaged hoses and valve inserts immediately to avoid pressure loss.
- Storage Guidelines: Store unused bearings, seals, and precision parts in a dry, dust-free environment (humidity ≤60%) to prevent corrosion, material degradation, and contamination.
We supply the following spare parts:
| Spare parts for drilling pumps JWS400 | |||
| Sr | Part Number | Description | UOM |
| 1 | 1714028 | Crankshaft 1714028 | pcs |
| 2 | 41743 | Connecting rod bearing JWS-400/340 1714012 | pcs |
| 3 | 4600075 | Input shaft bearing 4600075 | pcs |
| 4 | B 10920 SKF | Seal B 10920 SKF | pcs |
| 5 | 1714299 | Retainer 1714299 | pcs |
| 6 | 1PO183-z | Extension rod “GD” 1PO183-z | pcs |
| 7 | DN381839 | Filter element RAS DN381839 | pcs |
| 8 | 1714512 | Shaft 1714512 | pcs |
| 9 | 1310.58 5/8 | Cardan shaft 1310.58 5/8 | pcs |
| 10 | DRIVELINE-1880-JWS-400 | Cardan shaft DRIVELINE-1880-JWS-400 | pcs |
| 11 | 1810 | Cardan Spacer 1810 | pcs |
| 12 | 1715005 | Crosshead CROSSHEAD 1715005 | pcs |
| 13 | KMS1OB02X1544SS | Lubrication pump KMS1OB02X1544SS | pcs |
| 14 | 12GC2 | Bearing 12GC2 | pcs |
| 15 | V102-A9B33600-M | Belt adjustable V-shape-V102-A9B33600-M | pcs |
| 16 | 1294189 | Nozzle for irrigation system 1294189 | pcs |
| 17 | 5702085-181 | Chain RC-80-5 5702085-181 | pcs |
| 18 | 1714000 | Connecting rod assembly 1714000 | pcs |
| 19 | 1714296 | Intermediate rod 1714296 | pcs |
| 20 | 602-0699 | Pressure gauge (0-160 PSI) 602-0699 | pcs |
| 21 | 602-0085 | Pressure gauge (0-3000 PSI) 602-0085 | pcs |
| 22 | A662-CR596 | Radiator A662-CR596 | pcs |
| 23 | 63294 | Pressure gauge 0-1000 63294 | pcs |
| 24 | 63296 | Pressure gauge 0-3000 63296 | pcs |
| 25 | 63336 | Pressure gauge 0-600 63336 | pcs |
| 26 | 602-0141 | Pressure gauge 0-600 psi 602-0141 | pcs |
| 27 | 63297 | Pressure gauge 0-6000 63297 | pcs |
| 28 | 02250163-427 | Pressure gauge 2.5″ 02250163-427 | pcs |
| 29 | 5280K15 | Coupling BRS 1″ MCM 5280K15 | pcs |
| 30 | 5280K14 | Coupling BRS 3/4″ MCM 5280K14 | pcs |
| 31 | 9,510,290,047 | Lubrication pump 9510 290 047 | pcs |
| 32 | 5280K23 | Nipple BRS 1″ MCM 5280K23 | pcs |
| 33 | 5280K22 | Nipple BRS 3/4″ MCM 5280K22 | pcs |
| 34 | NBFI2857000 | Radiator assembly NBFI2857000 | pcs |
| 35 | Power shaft assembly JWS-400 | pcs | |
| 36 | 801-16-BLK-RL | Parker Push-Lok Hose 1″ 801-16- BLK- RL | M |
| 37 | 801-12-BLK-RL | Parker Push-Lok Hose 3/4″ 801-12-BLK-RL | M |
| 38 | G-1717602 | Crankshaft complete G-1717602 | pcs |
| 39 | G1716004 | Crosshead assembly G1716004 | pcs |
| 40 | 1713981 | Gearbox repair kit 1713981 | pcs |
| 41 | G-1717620 | Lubrication system repair kit G-1717620 | pcs |
| 42 | 46095027 | Blank 0x30x135 Ecorubber-H 46095027 | pcs |
| 43 | 46040129 | Blank 202x238x154 T-Ecopur 46040129 | pcs |
| 44 | 30877 | Blank 28x66x154 H-Ecopur 30877 | pcs |
| 45 | 32338 | Blank 55x95x150 Ecoflon 2 32338 | pcs |
| 46 | 46040057 | Blank 56x94x154 T-Ecopur 46040057 | pcs |
| 47 | 46095063 | Blank 90x140x135 EcorubberN 46095063 | pcs |
| 48 | 11089276 | Proportional solenoid type 11089276 | pcs |
| 49 | 2P110355 | Valve insert 2P110355 | pcs |
| 50 | Repair kit NH2M | pcs | |
| 51 | D16ME16 | Angle fitting D16ME16 | pcs |
7. Field Failure Repair Cases
Case 1: JWS400 Connecting Rod Bearing Failure
Scenario: A JWS400 drilling pump experienced abnormal noise and reduced pumping efficiency due to worn connecting rod bearings (1714012), risking crankshaft damage.
Solution: Replacement of 72 sets of OEM-matching connecting rod bearings and re-lubrication of the power assembly restored smooth operation and full pumping torque.
Outcome: Pump resumed normal mud circulation within 3 hours, avoiding costly crankshaft replacement and drilling downtime.
Case 2: Inaccurate Mud Pressure Readings
Scenario: Faulty 0–3000 PSI pressure gauges (602-0085) provided erratic pressure readings, leading to over-pumping risks and inconsistent mud delivery.
Solution: Installation of calibrated replacement pressure gauges restored accurate pressure monitoring, allowing operators to maintain optimal mud pressure levels.
Outcome: Pump pressure stabilized, ensuring safe and efficient drilling mud circulation.
Case 3: Lubrication System Malfunction
Scenario: A clogged lubrication pump (KMS1OB02X1544SS) caused insufficient oil flow to the JWS400 pump’s crankshaft, leading to overheating and wear threats.
Solution: Replacement of the faulty lubrication pump and installation of a new filter element (DN381839) restored consistent lubrication.
Outcome: Crankshaft temperature normalized, extending the service life of power transmission components.
8. Frequently Asked Questions (FAQ)
| Question | Answer |
| Are these parts compatible only with the JWS400 drilling pump? | Yes, all spare parts are designed exclusively for the JWS400 model, with select bearings and seals also compatible with JWS340 pumps, matching OEM part numbers for perfect fit. |
| How do I cross-reference my existing JWS400 part number? | Match your current part’s unique OEM number (e.g., 1714028, 41743, 602-0085) with the listed part numbers to select the exact replacement component for your pump. |
| Do these parts meet API drilling pump standards? | Yes, all components comply with API 7K standards for drilling pump equipment, using high-grade materials tested to withstand harsh oilfield operating conditions. |
9. Procurement Guidance & Call to Action
