Turkmenistan Onshore Drilling Rig Spare Parts

Product Introduction

This all-inclusive spare parts collection covers every critical system for Turkmenistan-based drilling rigs, including rig structural components, diesel engine repair parts, winch transmission spares, air compressor replacements, circulation system valves, CNS pump internals, cementing unit fittings, and standard industrial consumables. All parts are direct-fit OEM equivalents, designed for seamless installation without modifications, eliminating compatibility errors common with generic aftermarket parts. The lineup is curated specifically for Turkmenistan’s desert drilling environment, prioritizing high-durability, dust-resistant, and long-life components to match the rigors of local oilfield operations.

Functional Specifications

• Rig & Power Drive Parts: Spline connections, cardan shafts, and friction components ensure stable power transmission between motors, gearboxes, and drilling equipment; high-elastic couplings absorb vibration to protect drive systems under heavy load.
• Doosan PU222TI Engine Parts: Cylinder liners, fuel injectors, oil filters, and water pump components maintain optimal engine combustion, cooling, and lubrication; high-pressure fuel pumps and starter motors deliver reliable ignition and power output for 588kW, 2100rpm operation.
• Winch & Compressor Parts: LBU-1200 winch shafts, brake pulleys, and friction coils enable smooth hoisting and reliable braking; 4VU1-5/9 compressor piston rings, crankshafts, and valves maintain consistent air pressure for rig pneumatic systems.
• Circulation & Pump Parts: DN-rated gate valves, shock-absorbing clips, and CNS pump impellers ensure stable mud and water circulation; wear-resistant plungers and sealing rings prevent leaks in high-pressure drilling pump systems.

Structural Characteristics

All drilling rig spare parts feature rugged, desert-rated construction: metal components use forged alloy steel with anti-corrosion coating to resist sand and dust abrasion; sealing elements use oil/gas-resistant paronite and high-pressure rubber to maintain integrity in extreme temperatures; bearings and shafts comply with DIN and GOST standards for precision fit and load capacity; wear components (friction discs, piston rings) use heat-treated materials to extend replacement intervals. Parts are designed for tool-friendly on-site installation, minimizing repair time during critical drilling windows.

Applicable Operating Conditions

These parts are engineered exclusively for Turkmenistan onshore drilling environments and core equipment, including:

• ZJ70D and ZJ70DB 7000m-class drilling rigs (2010/2015 models)
• Doosan PU222TI 588kW diesel engines and LBU-1200 drilling winches
• 4VU1-5/9 M4UHL4 air compressors and CNS series centrifugal water pumps
• F-1300/F-1600 drilling pumps and cementing unit circulation systems
• Turkmenistan desert conditions: high dust, extreme temperature swings, and 24/7 continuous drilling

Maintenance & Servicing Recommendations

1. Pre-Installation Inspection: Verify OEM part numbers against rig technical drawings; clean mounting surfaces to remove sand and debris; inspect bearings, seals, and shafts for wear or damage before installation.
2. Engine System Maintenance: Replace Doosan PU222TI oil/fuel filters every 1,000 operating hours; inspect cylinder liners and piston rings for wear every 3,000 hours; torque fasteners to specified values to prevent sand-induced loosening.
3. Winch & Drive Care: Lubricate LBU-1200 winch shafts and cardan joints monthly; inspect friction coils and brake belts for wear every 2,000 hours; replace worn spline connections to avoid power transmission failure.
4. Circulation System Upkeep: Check gate valves and sealing clips for leaks every 1,500 hours; clean CNS pump impellers to remove sediment; replace worn plungers and valve seats in drilling pumps to maintain pressure.
5. Post-Installation Testing: Run equipment at partial load to check for abnormal noise, leaks, or vibration; verify pressure ratings for pumps and compressors; confirm engine and winch performance metrics post-repair.

We supply the following spare parts:

	Basic drilling, power and processing equipment
1	Drilling pump “F-1300” with diesel drive SAT-3508V, installation supervision (China, USA)		Set
7	LBU-1200 winch		Set
9	Diesel engine “G12V190PZL-1”, installation supervision (China)	«G12V190PZL-1»	Set
16	Air compressor 4VU1-5/9 M4UHL4	GOST 2405-88 14040.70.150	Set
18	ZGQ 1/4 Degasser (China)	ZGQ 1/4	Pcs
19	Kaskad-40 degasser	Kaskad-40	Pcs
20	Transmission box “Allison-S5610H” (China or USA)	29537462	Pcs
21	Transmission box “Allison-S5620AR” (China or USA)	29537301	Pcs
22	Gearbox variable KPZ-900D	KPZ-900D	Pcs
23	Diesel engine “Doosan” PU222TI, 588 kW, 2100 rpm, installation supervision (South Korea)		Set
24	Control panel CH6U-76 “Upetrom” 2-x battery (Romania)	430-32.00.00.00.0	Pcs
25	Pneumatic grinder or equivalent	“PSHM-125 “	Pcs
26	Electric Hand Grinder (large)		Pcs
27	Electric hand grinder (small)		Pcs
28	Electric drill manual (large)		Pcs
29	Electric drill manual (small)		Pcs
30	Cantilever pump 3K6-K 45/53 or aralog	3K6-K 45/53	Pcs
31	4K12-K 90/35 cantilever pump or equivalent	4K12-K 90/35	Pcs
32	Centrifugal pump K 80x 50x 200 with electric motor assembly or equivalent		Set
33	Centrifugal pump K 100-65-200 with electric motor assembly or equivalent		Set
34	Pipe cutting machine 11KW, 400V, 50Hz or equivalent	«ZMM» 1H983	Pcs
35	Heavy crawler truck TGP-70	TGP-70.02.01.000	Pcs
36	TP-35 transport trolley	TP-35.00.000	Pcs
37	KPB-3M crane or equivalent	GOST 22584-77	Pcs
39	NJ-4m3 Single-shaft Clay Mixer (China)		Set
40	Hydraulic brake UTG-1450	GOST 15150-69	Pcs
	Spare parts for drilling rig ZJ70D(2010) ZJ70DB (2015)
54	Spline connection between electric motor and gearbox for ZP-375 rotor		Set
55	Spline connection between electric motor and pulley for F-1600 pump		Set
58	Plunger Pump	YB05037	Pcs
	Spare parts for the circulation system
243	Gate valve DN 100 PN 2.5 MPa		Pcs
244	Shock-absorbing gelatin clip DN80 (element)		Pcs
245	Shock-absorbing gelatin clip DN100 (element)		Pcs
246	Shock-absorbing gelatin clip DN150 (element)		Pcs
247	Shock-absorbing gelatin clip DN200 (element)		Pcs
248	Shock-absorbing gelatin clip DN250 (element)		Pcs
249	Shock-absorbing gelatin clip DN300 (element)		Pcs
250	ZG-100×35 MPa drill manifold connection oil seal	GK 010022	Pcs
	Spare parts for diesel engine “Doosan” PU 222TI
260	Cylinder liner assembly “DOOSAN” PU222TI	65.01201-0312C	Pcs
261	DOOSAN pipe charger	65.09100-7052	Pcs
262	DOOSAN pipe charger	65.09100-7160	Pcs
263	Generator 24V	300901-00007	Pcs
264	Starter 24V	65.26201-7074D	Pcs
265	DOOSAN Cylinder Head Sealer	51.03901-0338	Pcs
266	Complete water pump	400921-00016	Set
267	Water Pump Bearing	65.93410-0087	Pcs
268	Mechanical seal of the water pump	65.06520-6007	Pcs
269	Belt (V-BELT) L=1425×9. 5	65.96801-0062	Pcs
270	Belt (V-BELT) L=1285×9. 5	65-96 801-0134	Pcs
271	Oil filter element	65.05510-5020B	Pcs
272	Coarse fuel filter “DOOSAN” PU 222 TI	65.12501-7023В	Pcs
273	Fine fuel filter “DOOSAN” PU 222 TI	65.12501-7036	Pcs
274	Oil cooler	65.05601-7135	Pcs
275	Water radiator “DOOSAN” PU 222 TI	65.06100-8032	Pcs
276	Spray nozzle assembly	65.10101-7053	Pcs
277	Water pump gasket	65. 06901A0074	Pcs
278	DOOSAN piston PU 222 TI	65.02501-0708	Pcs
279	Piston rings	65.02503-0158         65.02503-0159	Set
280	Connecting rod “DOOSAN” PU 222 TI	150121-00104	Pcs
281	Root shaft liner	65.01110-0070    65.01110-0080	Set
282	Crankshaft assembly	150107-00177	Pcs
283	Connecting rod insert “DOOSSAN” PU 222 TI	65.02410-0100	Pcs
284	Connecting rod insert “DOOSSAN” PU 222 TI	65.02410-0200	Pcs
285	High pressure fuel pump assembly	65.11101-7334	Pcs
286	Oil pump “DOOSAN” PU 222 TI	65.05100-6043А	Pcs
287	Oil pressure switch “DOOSAN” PU 222 TI	65.27441-7009	Pcs
288	Air filter element	65.08304-6005	Pcs
289	DOOSAN PU222TI Fuel filter Bracket	65.12540-5030	Pcs
290	DOOSAN cooling thermostat PU222T	65.06402-0006	Pcs
291	DOOSAN PU 222 TI impeller (cooling fan)	65.06601-5048	Pcs
292	Valve tappet	65.04302-0026	Set
293	Oil cooler seal “DOOSAN” PU 222 TI	65.05901-0014	Pcs
294	Instrument control panel “DOOSAN” PU222TI	65.061700-6031В	Pcs
295	Moto sensor on diesel “DOOSAN” PU222TI	65.27161-6001	Pcs
296	Sensor-tachometer (on the flywheel) “DOOSAN” PU222TI	65.27103-7007	Pcs
297	DOOSAN PU 222 TI Oil pressure sensor	65.27431-6004	Pcs
	Spare parts for the power drive
298	VOITH cardan clutch 12502463210	К060.199.1034.N50	Pcs
299	Driveshaft 125.024605100 A	G040 1644	Set
300	Friction ring 125.01869110	К060.057.0020	Set
301	Friction disc 125.0175580001	К060.055.0021	Set
302	High-elastic coupling 125.0157030001	К060.152.0415.N50	Set
303	Connecting element 125.0079620001	К060.050.1037	Set
304	Cardan crosspiece with clutch bearing “VOITH”	DIN 71412	Pcs
	Different pumps
330	Rod cooling pump 32-PL, vertical with electric motor	F-1600, F-1300	Set
331	Rod cooling pump 32-PL, horizontal with electric motor	F-1600, F-1300	Set
	Spare parts for drilling winch LBU-1200
342	Lifting shaft	4062.78.150	Pcs
343	Transmission shaft of the 5th speed	4062.79.000	Pcs
344	Coil friction shaft	4062.80.000	Pcs
345	Winch gearbox shaft I	4062.91.151	Pcs
346	Winch gearbox shaft II	4062.99.104	Pcs
347	RL-11000 winch gearbox	4062.99.150	Pcs
348	Brake Pulley	4062.78.136	Pcs
349	Gimbal shaft with hook (L=2680 mm) 01.052.200-03	4062.90.516	Pcs
350	Cardan shaft (L=2100 mm)	4062.90.500	Pcs
351	Cardan shaft crosspiece spline	4062.90.517	Pcs
352	Keyway cardan shaft crosspiece	4062.90.518	Pcs
353	LBU-1200 rotor drive	4062.92.001	Pcs
354	Swivel double, 2-cantilevered	4062.39.100	Pcs
355	Pinwheel 4-10 03.2067.002	4062.97.200	Pcs
356	Swivel flange 2-16 (single)	44038.39.002	Pcs
357	2-valve crane	4008.71.500-2	Pcs
358	4-valve crane	4003.71.220-10	Pcs
359	4-valve tap valve	4008.71.243	Pcs
360	Discharge valve	4062.71.070	Pcs
361	Distributor REP 1-1-20 1,0 MPa	14088.95.250-01	Pcs
362	Friction Coil Pulley	4062.80.121	Pcs
363	Friction coil Tape	4062.84.201	Pcs
364	Friction coil cover plate	4066.43.127	metre
365	Brake belt	4062.81.000	Pcs
366	Cam coupling	4062.78.123	Pcs
367	Driller’s remote control	4062.95.160	Pcs
	Spare parts for the compressor ” 4VU 1-5 / 9M4UHL4 “
405	Crankshaft with bearing 302601033N	302-601-03 3P 1	Pcs
406	I-stage piston assembly	302-601-06-3/03-24	Set
407	II-stage piston assembly	302-601-06-3/03-25	Set
408	1st stage cylinder block		Pcs
409	2nd stage cylinder block		Pcs
410	Counter drive for mechanical compressor	4062.70.050	Pcs
411	U-125 compression piston ring assembly	302-601-06-3/04-34	Set
412	Piston ring, oil-removing assembly MP-125	31680/04-132	Set
413	U-210 compression piston ring assembly	302-601-06-3/04-31	Set
414	Piston ring, oil-removing MP-210 assembly	31677/04-130	Set
415	Locking ring		Pcs
416	Connecting rod assembly	302-601-04 A	Set
417	Air swivel (left) for counter-drive	26007.3040.16	Pcs
418	Valve stage 2 head		Pcs
419	Piston pin		Pcs
420	1st stage saddle		Pcs
421	1st stage plate		Pcs
422	2nd stage saddle		Pcs
423	2nd stage plate		Pcs
	Spare parts for the air collector BKZ V-2, 7m3 or equivalent
424	Safety valve spring T31MS3150mm	ТУ1078.21.272-88	Pcs
425	Sump-oil separator for the air collector	BKZ=2.7 m3	Pcs
	Spare parts for the ASDU power unit
426	Gearbox power(step-down) RTS-1.53 rpm-1500		Pcs
427	I-th shaft of the power gearbox RTSS-1.53	4062.38.010	Pcs
428	II-th shaft of the power gearbox RTSS-1.53	4062.38.012	Pcs
429	Driving shaft KP3-900D		Pcs
430	Driven shaft KP3-900D		Pcs
431	Pulley for 2-pulley power unit ASDU		Pcs
432	Coupled pulley for KP3-900D ASDU		Pcs
433	Oil seal of step-down gearbox 1, 2x105x38-3	GOST 6678-72	Pcs
434	Driving half coupling	4062.06.000	Pcs
435	Faceplate	4062.38.303	Pcs
436	Sump tank (oil tank V=670 liters) for KP3-900D ASDU	4020.68.000	Pcs
437	KPZ-900D Oil pump	type G-11-25	Pcs
	Spare parts for step-down gearbox JS-1200 (China)
438	I-th shaft of a power gearbox with bearings		Pcs
439	II-th shaft of a power gearbox with bearings		Pcs
440	Bearing 232218. C. A./C/3W33 140x250x68 3528		Pcs
441	Step-down gearbox (1,53) (900kW) (1500rpm) (1275x1085x980)	JS-1200	Pcs
442	Gimbal clutch assembly	W51.5×870	ct
	Spare parts for the CS-3D circulation system
443	Shut-off valve coupling ø25 mm		Pcs
444	Shut-off valve coupling ø20 mm		Pcs
445	Shut-off valve coupling ø15 mm		Pcs
446	Shut-off valve coupling ø 80mm	DN80 Ru1. 0	Pcs
447	Shut-off valve coupling ø 80mm	DN80 Ru1, 6	Pcs
	Spare parts for the R-700 rotor or equivalent
448	TR-350 rotor transmission (366911)	4062.92.000	Pcs
449	Drive shaft of the R-700 rotor	14016.45.010	Pcs
450	Roller guide insert	4062.45.450	Pcs
451	R-700 rotor insert	1416.45.270	Pcs
452	R-560 rotor Jaw	4-8-41/82	Pcs
453	Asterisk Z=19	4045.45.520	Pcs
454	Asterisk Z=21	4045.45.511	Pcs
455	Bevel gear Z-18	14016.45.015	Pcs
456	Cord 4c ø8 mm. L=3,0 M.		Pcs
457	Cord 4c ø5 mm. L=6,0 M.		Pcs
458	Oil seal 210		Pcs
459	Main support (bearing 1687/770)		Pcs
460	Auxiliary support (bearing 1688/770)		Pcs
	Spare parts for the KP crane
469	Crane rotation reducer with electric motor.PBC-3M or equivalent		Set
	Lifting equipment
473	Electric hoist 2 tons 6m high		Pcs
	Perforation gate valve
475	ZPU-180x700HL perforation gate valve or analog		Pcs
476	ZPU-150x350HL perforation gate valve or analog		Pcs
	Spare parts for hydraulic lift CH6U-76 ” UPETROM “(Romania)
477	Triple plunger pump 3RU-20	614.20-00.00.00.0	Pcs
	Electric gas welding equipment, tools and accessories
479	Welding Transformer VX1-400 (China)	“VX1-400”	Pcs
480	ANO electrode ” ø4 mm		kg
481	ANO electrode ” ø3 mm		kg
482	UONI electrode ø4 mm		kg
483	UONI electrode ø3 mm		kg
484	Cutter for manual cutting RZP-902 or equivalent		Pcs
485	Gearbox propane BPO 5-4 or analog		Pcs
486	Oxygen reducer BKO 504 or equivalent		Pcs
487	VK-74 oxygen cylinder valve or equivalent		Pcs
	Rolling bearings
505	Bearing 2322		Pcs
523	Bearing 10079/710		Pcs
	High pressure hoses
528	Rubber sleeve ø9 mm 20 atm		metre
529	Rubber sleeve ø15 mm		metre
530	Rubber sleeve ø20 mm		metre
	Sealing materials
531	Stuffing box ø 8mm	8x8mm	kg
532	Stuffing box ø10 mm	10x10mm	kg
533	Stuffing box ø12 mm	12×12мм	kg
534	Stuffing box ø15 mm	15x15mm	kg
535	Stuffing box ø22 mm	22x22mm	kg
536	Stuffing box made of impregnated hemp	14 x14 mm	kg
537	Stuffing box made of impregnated hemp	16 x16 mm	kg
538	Stuffing box made of impregnated hemp	18 x18 mm	kg
539	Stuffing box made of impregnated hemp	19 x19 mm	kg
540	Oil and gas resistant paronite	PMB-1 mm	kg
541	Oil and gas resistant paronite	PMB-2 mm	kg
542	Oil and gas resistant paronite	PMB-3 mm	kg
543	Oil and gas resistant paronite	PMB-4 mm	kg
544	FUM tape 0.1-1.0	92480800011	kg
545	FUM tape 0.08-1.5	92480800011	kg
	Pump control equipment “Water supply system “
559	CNS 300×300 with electric motor 400 kW 1500 rpm not explosion-proof or equivalent	CNS 300×300	Set
560	CNS 300×240 with electric motor 315 kW 1500 rpm not explosion-proof or equivalent	CNS 300×240	Set
561	CNS 300×180 with electric motor 315 kW 1500 rpm not explosion-proof or analog	CNS 300×180	Set
562	CNS 180×255 with electric motor 250 kW 1500 rpm not explosion-proof or equivalent	CNS 180×255	Set
563	CNS 180×170 with electric motor 200 kW (6 kv)1500 rpm not explosion-proof or equivalent	CNS 180×170	Set
564	CNS 180×128 with electric motor 132 kW 1500 rpm not explosion-proof or analog	CNS 180×128	Set
565	CNS 180×85 with electric motor 75 kW 1500 rpm not explosion-proof or equivalent	CNS 180×85	Set
566	CNS 850×240 with electric motor 800 kW 1500 rpm not explosion-proof or equivalent	CNS 850×240	Set
567	Pump D 200/36 with electric motor 45 kW 1500 rpm not explosion-proof or equivalent	D 200/36	Set
568	Pump 10 ND with electric motor 132 kW 1500 rpm not explosion-proof or equivalent	10 ND	Set
569	OMEGA 250-800A pump or equivalent		Set
570	Pump K40x40 or equivalent		Set
	Spare parts for CNS pump 850
571	CNS-850 Val		Pcs
572	CNS-850 1-stage impeller	MSG-7-01-118-1	Pcs
573	CNS-850 Impeller	MSG-7-01-178	Pcs
574	CNS-850 Remote Bushing	MSG-7-01-126-1	Pcs
575	CNS-850 Hydraulic lock sleeve	MSG-7-01-112	Pcs
576	CNS-850 Guiding device	MSG-7-01-119	Pcs
577	CNS-850 Protective sleeve		Pcs
578	CNS-850 Bearing Bushing		Pcs
579	CNS-850 Guide device of 1 stage		Pcs
580	CNS-850 Bushing 190312	MSG-7-01-102,00	Pcs
581	CNS-850 Nut 1904	MSG-7-01-107	Pcs
582	CNS-850 Bushing gland 1905	MSG-7-01-108	Pcs
583	CNS-850 Shirt shaft 1906	MSG-7-01-109,1	Pcs
584	CNS-850 Front bracket	MSG-7-01-114	Pcs
585	CNS-850 Suction Cap 1909	MSG-7-01-116	Pcs
586	CNS-850 Ring uplot.1st stupa.1910	MSG-7-01-117	Pcs
587	CNS-850 Working wheel of the 2nd stage 191112	MSG-8-01-118-1	Pcs
588	CNS-850 Sealing ring 1913	MSG-7-01-121	Pcs
589	CNS-850 Sealing ring 1914	MSG-7-01-122	Pcs
590	CNS-850 Guide device for issuing 1915	MSG-7-01-123	Pcs
591	CNS-850 Unloading Sleeve 1916	MSG-7-01-125-1	Pcs
592	CNS-850 Pressure Cap 1918	MSG-7-01-132-1	Pcs
593	CNS-850 Rear bracket 1919	MSG-7-01-135-1	Pcs
594	CNS-850 Rotary Nut 1924 12	MSG-7-01-142-1	Pcs
595	CNS-850-240 Shaft (2 stage)		Pcs
	Spare parts for CNS pump 300
596	CNS-300 Rotor Nut	8MS 7.01.07	Pcs
597	Body of the central nervous system guide device 300-120-600	8MS 7.0119-2	Pcs
598	CNS-300 Guide Device Ring	CNS 300-120	Pcs
599	CNS-300 Cable for sealing the body of the guide device	CNS 300-120	Pcs
600	CNS-300 Working wheel when issuing	8MS 7.0118-1	Pcs
601	CNS-300 Sealing ring	8MS 7.0120	Pcs
602	CNS-300 Sealing ring	8MS 7.0121	Pcs
603	CNS-300 Unloading Disk	8MS 7.0109	Pcs
604	CNS-300 Shaft of 3 stages. of the pump	TSNS300-180	Pcs
605	CNS-300 Bearing Bushing		Pcs
606	CNS-300 Cuff	Gost 87-52-79	Pcs
607	CNS-300 Throttling Bushing		Pcs
608	CNS-300 impeller	8MS 7.0118	Pcs
609	CNS-300 impeller 1 stage		Pcs
610	CNS-300 shirt shaft	8MS 7.0126	Pcs
611	CNS-300 Remote Bushing	8MS 7.0113	Pcs
612	CNS-300 Hydraulic lock sleeve	TSNSN-300-180.001	Pcs
613	CNS-300 Front bracket	8MS 7.0129	Pcs
614	CNS-300 Rear bracket	8MS 7.0103	Pcs
615	CNS-300 Discharge Bushing	8MS 7.0114	Pcs
616	CNS-300 Unloading Ring	8MS 7.0112	Pcs
617	CNS-300 Unloading Ring	8MS 7.0111	Pcs
618	CNS-300 Guiding device	8MS 7.01.17-1	Pcs
	Spare parts for CNS pump 180
619	CNS-180 Impeller I-stage	180 x 255	Pcs
620	CNS-180 Shirt Shaft	CNS 180-255. 001	Pcs
621	CNS-180 Remote Bushing	6MS 6-0113	Pcs
622	CNS-180 Hydraulic lock sleeve	6MS 6-0126	Pcs
623	CNS-180 Discharge Bushing	6MS 6-0114	Pcs
624	CNS-180 Discharge Ring	CNS 180-255 6 MS-0119	Pcs
625	CNS-180 Guiding device	6MS 6-0117-1	Pcs
626	CNS-180 Throttling sleeve		Pcs
627	CNS-180 Front bracket		Pcs
628	CNS-180 Rear bracket		Pcs
629	CNS-180 Bearing Bushing		Pcs
630	CNS-180 Cuff	Gost 87-52-79	Pcs
631	CNS-180 Sealing ring	6 MS 6-0121	Pcs
632	CNS-180 Sealing ring	6 MS 6-0122-1-02	Pcs
633	CNS-180 Working wheel	6 MS 6-0118	Pcs
634	CNS-180 Guide device housing	6 MS 6-01. 129	Pcs
635	CNS-180 Guide Device Ring	CNS 180×85 85.1.425.01.009	Pcs
636	CNS-180 3-stage pump shaft	CNS 180×128	Pcs
637	CNS-180 5-stage pump shaft	CNS 180×212	Pcs
	Spare parts for the cementing unit
638	Plug valve d=50 P=70 (Pump SIN 64.00.100.000)	2KMN	Pcs
639	Plug valve d=25 P=70 (Pump SIN 64.00.100.000)	2KMN	Pcs
640	Articulated elbow d=50 P=70 (Pump SIN 64.00.100.000)	KSH-70	Pcs
641	Plunger d=100-7-72 (Pump SIN 64.00.100.000)		Pcs
642	5S pump tripleks valve SP-507 with proportional cover (SP-507 pump)	SP-507 tripleks	Pcs
643	Receiving hose d=100 L=4,5 (NSP-32 pump)	SIN 30.01.0700000	Pcs
644	Receiving hose D=75 L=3m (NSP-32 pump)		Pcs
645	High pressure hose P=25 L=10 (D=50) (NSP-32 Pump)		Pcs
646	Discharge hose L=10 (d=50) (Pump NSP-32)		Pcs
647	Adjustable nozzle 2x1050mm		Pcs
648	Swivel elbow 22 ” R2 ” x1050 bar (Pump SIN 64.00.100.000)		Pcs
649	Plug valve 2x2nkt 60 P=105 Mpa (Pump SIN 64.00.100.000)	GOST 633-80	Pcs
650	Plug valve 2x1nkt 60 P=105 Mpa (Pump SIN 64.00.100.000)	GOST 633-80	Pcs
651	Cork crane 2x1nkt 60 P=105 Mpa	GOST 633-80	Pcs
652	Piston rod 9T.2.5. L=880 mm (NPS-32 pump)	9T.2.5	Pcs
653	Valve d=111 mm 9T.2.69 (NPS-32 pump)	9T.2.69	Pcs
654	Valve Seat d=111T. 118A (NPS-32 Pump)	T.118A	Pcs
655	Ball valve d=25x40MPa (NPS-32 Pump)		Pcs
656	Cylinder sleeve d=100 (NPS-32 Pump)	6G-102	Pcs
657	Cylinder sleeve d=127 (NPS-32 Pump)	6G-104	Pcs
658	Ball valve d=50×40 Mpa (NPS-32 Pump)		Pcs
659	Gear pump NSH-10 (NPS-32 pump)		Pcs
660	Gate valve d=100 (4″) (NPS-32 pump)	SIN 100.13.000	Pcs
661	Worm NPS 01.029 A (Pump NPS-32)	NPS 01.029A	Pcs
662	Articulated elbow KSH-40 d=50 P=40 (Pump NPS-32)	KШ-40	Pcs
663	Piston D=127 mm (NPS-32 pump)	9T.2.34	Pcs
664	Cylinder sleeve D=115 (NPS-32 Pump)	6G-103	Pcs
665	Crosshead assembly (NPS-32 Pump)	9G.01.200	Pcs

On-Site Turkmenistan Drilling Rig Fault Repair Cases

Case 1: Doosan PU222TI Engine Oil Leak & Overheating

A Turkmenistan drilling rig’s Doosan PU222TI engine experienced persistent oil leaks and overheating, traced to a worn water pump mechanical seal and clogged oil cooler. The damaged seal caused coolant loss, while debris in the oil cooler blocked heat dissipation. Replacing the water pump seal, oil cooler, and associated gaskets restored normal cooling and eliminated leaks.

Case 2: LBU-1200 Winch Brake Failure

An onshore ZJ70DB rig’s LBU-1200 winch suffered inconsistent braking and slipping during hoisting, caused by worn friction coils and a damaged brake pulley. Desert dust accelerated friction material wear, reducing braking torque. Installing new friction coils, a replacement brake pulley, and adjusting brake tension restored safe, reliable winch operation.

Case 3: ZJ70D Drilling Pump Circulation Leak

A ZJ70D rig’s F-1600 drilling pump developed high-pressure leaks in the circulation manifold, due to failed ZG-100×35 MPa oil seals and worn shock-absorbing clips. The leaks disrupted mud circulation and halted drilling. Replacing the faulty seals and clips restored pressure integrity and resumed drilling operations.

Frequently Asked Questions (FAQ)

Question	Answer
Are these parts compatible with both ZJ70D and ZJ70DB drilling rigs?	Yes, this parts catalog includes dedicated spares for both ZJ70D (2010) and ZJ70DB (2015) rigs, with exact OEM part numbers and fitments for each model’s drive and circulation systems.
How often should Doosan PU222TI filter elements be replaced?	Oil filter elements should be replaced every 1,000 operating hours, fuel filters every 1,500 hours, and air filters every 2,000 hours to prevent engine clogging in dusty Turkmenistan conditions.
Do these parts meet GOST and API drilling standards?	All structural, power, and circulation parts comply with relevant GOST industrial standards and API 7K drilling equipment specifications, ensuring safety and performance for onshore operations.

Procurement Guidance & Closing Statement

For drilling teams operating ZJ70D/ZJ70DB rigs, Doosan PU222TI engines, and LBU-1200 winches in Turkmenistan’s onshore oilfields, this spare parts catalog provides a fully compliant, desert-optimized sourcing solution for all critical rig systems. Backed by strict OEM quality standards and precise part matching, these components eliminate compatibility risks, streamline on-site repairs, and provide a clear technical benchmark to resolve rig failures quickly. Whether stocking for routine preventive maintenance, emergency breakdown repairs, or full rig overhauls, these model-specific spare parts ensure adherence to global drilling safety standards, minimize costly downtime in remote desert locations, and preserve the long-term operational integrity of your drilling equipment. Secure the exact engine parts, winch components, circulation fittings, and consumables your Turkmenistan drilling rig needs to maintain uninterrupted, efficient, and safe 24/7 drilling operations.
