Detailed Product Introduction
This Derrick PG013 parts collection covers all critical wear and replacement components for the centrifuge’s core systems, including separation nozzles, bearing assemblies, sealing kits, valve components, mesh belt hardware, fasteners, and pump housing parts. It includes OEM-matched adjustable nozzle sleeves, ceramic shaft sleeves, precision bearings, high-performance O-rings, ball valves, mesh tension combs, and specialized fasteners, with cross-referenced Derrick OEM part numbers for seamless drop-in fit. The parts are curated to address the highest-failure areas of PG013 centrifuges, eliminating compatibility issues and reducing field repair and installation time significantly for both minor part replacements and full system overhauls, making it the definitive reference for reliable Derrick PG013 part sourcing.
Functional Performance & Value Highlights
- High-Efficiency Solids Separation: Precision-machined nozzle sleeves and cone bushings maintain consistent mud flow rates, boosting solids separation efficiency by 18% and reducing fluid loss.
- Zero Leakage Sealing: Industrial-grade O-rings, mechanical seals, and packing kits (graphite/Teflon) prevent mud and fluid leakage, protecting internal components and maintaining system pressure.
- Extreme Wear Resistance: Ceramic shaft sleeves, stainless steel supports, and hardened bearings resist abrasion from high-solids drilling mud, extending replacement intervals by 65%.
- Stable Mechanical Operation: Precision bearings, tensioners, and drive components eliminate vibration and misalignment, ensuring smooth centrifuge rotation and consistent performance.
Structural & Engineering Features
- OEM Drop-In Compatibility: All components match Derrick PG013 and DE-1000 original equipment mounting and connection specifications, requiring no custom modifications for field installation.
- Corrosion & Abrasion Resistance: 303/316 stainless steel, ceramic, and polyurethane materials withstand corrosive drilling fluids and abrasive solids, suitable for long-term harsh environment use.
- Modular Design: Pre-assembled seal kits, bearing sets, and nozzle assemblies simplify part identification and inventory management for maintenance teams.
- Industry Standard Compliance: All load-bearing and sealing parts meet API 13C and ISO 10426 standards for oilfield solids control equipment, ensuring regulatory compliance worldwide.
Applicable Operating Conditions
These Derrick PG013 spare parts are built for demanding oilfield solids control environments, suitable for:
- Routine maintenance, emergency breakdown repairs, and full overhauls of Derrick PG013 centrifuges and DE-1000 drum extension units
- Onshore and offshore drilling rig mud solids separation and fluid recycling systems
- High-solids drilling mud treatment, withstanding abrasive particulate and corrosive fluid conditions
- API-compliant solids control systems requiring certified Derrick OEM-compatible replacement parts
Professional Maintenance & Troubleshooting Recommendations
- Nozzle & Bushing Care: Inspect and clean adjustable nozzle sleeves (SCM-10523 series) every 300 operating hours; replace worn units to preserve separation efficiency.
- Bearing Inspection: Lubricate main and support bearings (CS10-RA series) quarterly, and replace worn bearings every 8,000 hours to prevent centrifuge vibration and failure.
- Seal System Maintenance: Replace O-rings, mechanical seals, and packing kits every 500 operating hours to eliminate fluid leakage and contamination.
- Mesh Belt & Tensioner Checks: Adjust mesh tension combs monthly and replace worn mesh belts (G0001913) every 6 months to maintain proper mud conveyance.
- Valve & Pump Servicing: Inspect ball valves and pump housings every 400 hours; clean or replace clogged components to ensure consistent fluid flow.
- We supply the following spare parts:
| № | Name | Part Number | Unit |
| 1 | Side support, stainless steel 16710-01 | 16710-01 | pcs |
| 2 | Adjusting bolt SST G0005479 | SST G0005479 | pcs |
| 3 | Set bolt 303 SST SCM-G0005479 | 303 SST SCM-G0005479 | pcs |
| 4 | Wear insert on the solids outlet side CS10-RA-630-IC | CS10-RA-630-IC | pcs |
| 5 | Ceramic shaft sleeve G0006015 | G0006015 | pcs |
| 6 | Gland bushing SCM-G0006004 | SCM-G0006004 | pcs |
| 7 | Nozzle sleeve (adjustable 0.500-0.375) SCM-10523-03 | SCM-10523-03 | pcs |
| 8 | Nozzle sleeve (adjustable 0.625-0.500) 403.028 (similar to 10523-02) | 403.028 (similar to 10523-02) | pcs |
| 9 | Nozzle sleeve (adjustable 0.625-0.500) SCM-10523-02 | SCM-10523-02 | pcs |
| 10 | Nozzle bushing 1.0 cone 10″ 6066-72 | 10″ 6066-72 | pcs |
| 11 | Nozzle bushing 1.5 cone 10″ 6066-73 | 10″ 6066-73 | pcs |
| 12 | Cone nozzle bushing 1.250 SCM-6066-57 | 1.250 SCM-6066-57 | pcs |
| 13 | Nut 5/8-11BRS NHHB-63-11 | 5/8-11BRS NHHB-63-11 | pcs |
| 14 | Triangular tip nut 10523-04 | 10523-04 | pcs |
| 15 | Tension nut G0005480 | G0005480 | pcs |
| 16 | Tension nut G0005480 (SCM-G0005480) | G0005480 (SCM-G0005480) | pcs |
| 17 | Lower cone nut 106-205 | 106-205 | pcs |
| 18 | Hexagon nut G0005428 | G0005428 | pcs |
| 19 | Nozzle sleeve nut SCM-6066-58 | SCM-6066-58 | pcs |
| 20 | Net tension comb, adjustable side 14611-01 | 14611-01 | pcs |
| 21 | Net tension comb, fixed side 14612-01 | 14612-01 | pcs |
| 22 | Replacement pad holder PP1494 | PP1494 | pcs |
| 23 | Conveyor compactor brush holder 1435701A | 1435701А | pcs |
| 24 | Conveyor compactor brush holder 1435702A | 1435702А | pcs |
| 25 | Mechanical jack G0005849 (SCM-G0005849) | G0005849 (SCM-G0005849) | pcs |
| 26 | Front curtain 3/16″х47 1/2″х20 PVK-120 with fastening | 3/16″ x47 1/2″ x20 PVK-120 with mounting | pcs |
| 27 | Brush drive sprocket bushing РР1462 | РР1462 | pcs |
| 28 | Ball valve APO-BV38 | APO-BV38 | pcs |
| 29 | Ball valve SCM-APO-BV38 | SCM-APO-BV38 | pcs |
| 30 | Ball valve Victaulic 2″ G0002077 | 2″ G0002077 | pcs |
| 31 | Wrench for net tensioning system 14734-01 (SCM-14734-01) | 14734-01 (SCM-14734-01) | pcs |
| 32 | Oil flinger bearing SCM-G0006006 | SCM-G0006006 | pcs |
| 33 | Sealing ring 3/4×3/32 SCM-G0003319 | 3/4×3/32 SCM-G0003319 | pcs |
| 34 | Sealing ring 4.875×0.125″ CS10-RA-325-00 covers | 4.875×0.125″ CS10-RA-325-00 caps | pcs |
| 35 | External sealing ring 8×0.125″ CS10-RA-321-00 covers | 8х0,125″ CS10-RA-321-00 caps | pcs |
| 36 | Impeller sealing ring SCM-G0006035 (G0006035) | SCM-G0006035 (G0006035) | pcs |
| 37 | Drum extension sealing ring 13.5×0.25″ CS10-RA-316-00 | 13,5х0,25″ CS10-RA-316-00 | pcs |
| 38 | O-ring feed accelerator CS10-RA-323-00 | CS10-RA-323-00 | pcs |
| 39 | Sealing ring, ext. liquid phase outlet end side CS10-RA-321-00 | CS10-RA-321-00 | pcs |
| 40 | Sealing ring, inner part on the liquid side CS10-RA-322-00 | CS10-RA-322-00 | pcs |
| 41 | O-ring, liquid phase drain pipe CS10-RA-316-00 | CS10-RA-316-00 | pcs |
| 42 | O-ring, solids outlet side CS10-RA-325-00 | CS10-RA-325-00 | pcs |
| 43 | S3515IC (CS10-RA-630-IC) solids outlet wear insert kit | S3515IC (CS10-RA-630-IC) | pcs |
| 44 | Brush replacement kit CCC-HB-040N30 | CCC-HB-040N30 | pcs |
| 45 | Set of openers CS10-RA-634-IC extension drum DE-1000 | CS10-RA-634-IC drum extension DE-1000 | pcs |
| 46 | Set of coulters CS10-RA-650-IC of drum head DE-1000 | CS10-RA-650-IC drum headrest DE-1000 | pcs |
| 47 | Housing seal kit SCM-G0006033 (G0006033) | SCM-G0006033 (G0006033) | pcs |
| 48 | Cone 10″ SCM-6066-51 complete | 10″ SCM-6066-51 assembly | pcs |
| 49 | Cone assembly 10″ 6066-51 | 10″ 6066-51 | pcs |
| 50 | Stuffing box with mechanical seal SCM-G0006017 (H20614-01-30A) | SCM-G0006017 (H20614-01-30A) | pcs |
| 51 | Cone body 4″ 10523-00 | 4″ 10523-00 | pcs |
| 52 | Cam mechanism housing 17-4РН SCM-14617-01 | 17-4РН SCM-14617-01 | pcs |
| 53 | Pump housing 6x5x14 G0006029 | 6х5х14 G0006029 | pcs |
| 54 | Pump housing 6x5x14 P25D564HR | 6х5х14 P25D564HR | pcs |
| 55 | Pump housing 8x6x14 G0006031 | 8х6х14 G0006031 | pcs |
| 56 | Rear bearing cap G0006009 | G0006009 | pcs |
| 57 | Cone cap 106-208 | 106-208 | pcs |
| 58 | Front bearing cap G0006007 | G0006007 | pcs |
| 59 | Load limiter cam 12748-00 | 12748-00 | pcs |
| 60 | Mesh belt G0001913 10 mesh for sieve conveyor | G0001913 | pcs |
| 61 | Elastic coupling EM10 6x5x14 for pump Premium 250 6x5x14 | EM10 6x5x14 for Premium 250 6x5x14 pump | pcs |
| 62 | Graphite packing SCM-G0006010 (G0006010) | SCM-G0006010 (G0006010) | pcs |
| 63 | Teflon packing SCM-G0006012 (G0006012) | SCM-G0006012 (G0006012) | pcs |
| 64 | Threaded cone tip 10523-01 | 10523-01 | pcs |
| 65 | Comb guide 14616-01 | 14616-01 | pcs |
| 66 | Load limiter DE-1000 125:1 13184-03 (SCM-13184-03) | DE-1000 125:1 13184-03 (SCM-13184-03) | pcs |
| 67 | Load limiter DE-1000 13184-01 | DE-1000 13184-01 | pcs |
| 68 | Side support 3/4″х27х3/8″ SCM-16710-01 corrosion-resistant steel | 3/4″ x27x3/8″ SCM-16710-01 corrosion-resistant steel | pcs |
| 69 | Cross support 1″x41 SCM-16710-04 corrosion-resistant steel | 1″ x41 SCM-16710-04 corrosion-resistant steel | pcs |
| 70 | Cross support 1/2″х40х1/2″ SCM-16710-02 corrosion-resistant steel | 1/2″x40x1/2″ SCM-16710-02 corrosion-resistant steel | pcs |
| 71 | Cross support 3/4″x40x1/2″ SCM-16710-03 corrosion-resistant steel | 3/4″x40x1/2″ SCM-16710-03 corrosion-resistant steel | pcs |
| 72 | Angled polyurethane fitting Victaulic SCM-6431-00 2″ 180 degrees | SCM-6431-00 2 ” 180 degrees | pcs |
| 73 | Floating suspension assembly with bolts SCM-520063 (1129-00) | SCM-520063 (1129-00) | pcs |
| 74 | Rear bearing SCM-G0006008 (G0006008) | SCM-G0006008 (G0006008) | pcs |
| 75 | Main bearing CS10-RA-512-00 solids centrifuge | CS10-RA-512-00 | pcs |
| 76 | Main bearing CS10-RA-513-00 liquid outlet centrifuge | CS10-RA-513-00 | pcs |
| 77 | Support bearing from the end of the liquid phase CS10-RA-513-00 | CS10-RA-513-00 | pcs |
| 78 | Support bearing from the end of the solid fraction CS10-RA-512-00 | CS10-RA-512-00 | pcs |
| 79 | Support bearing for conveyor CS10-RA-511-00 | CS10-RA-511-00 | pcs |
| 80 | Front bearing SCM-G0006005 (G0006005) | SCM-G0006005 (G0006005) | pcs |
| 81 | Conveyor thrust bearing CS10-RA-510-00 | CS10-RA-510-00 | pcs |
| 82 | Tensioner bearing 1 1/2″ G0001808 | 1 1/2″ G0001808 | pcs |
| 83 | Tape tensioner bearing 1″ G0001809 | 1″ G0001809 | pcs |
| 84 | Flanged bearing 1 1/2″ G0001810 (SCM-G0001810) | 1 1/2″ G0001810 (SCM-G0001810) | pcs |
| 85 | Flanged bearing 1″ G0001811 (SCM-G0001811) | 1″ G0001811 (SCM-G0001811) | pcs |
| 86 | Support ball bearing CS10-RA-510-00 at the outlet of the liquid phase | CS10-RA-510-00 | pcs |
| 87 | Support ball bearing CS10-RA-511-00 at the output of the solid phase | CS10-RA-511-00 | pcs |
| 88 | Variable drive assembly G0003579 | G0003579 | pcs |
| 89 | Pump casing gasket G0006034 (H10399-46-1) | G0006034 (H10399-46-1) | pcs |
| 90 | Front bearing cap gasket G0006042 (SCM-P25IBBCG) | G0006042 (SCM-P25IBBCG) | pcs |
| 91 | Support rib protector X-26″ 3660-05-30 material nitrile | X-26″ 3660-05-30 material nitrile | pcs |
| 92 | Reciprocating sliding spring SCM-G0005466 | SCM-G0005466 | pcs |
| 93 | Impeller 8x6x14 Art. No. G0006031 Derrick 250 | G0006031 Derrick 250 | pcs |
| 94 | Speed controller W954A03BBSF0621 | W954A03BBSF0621 | pcs |
| 95 | Drive belt BELT-5G3V-1000 | BELT-5G3V-1000 | pcs |
| 96 | Brush drive belt PP1465 | PP1465 | pcs |
| 97 | Pipe connection Victaulic 8″ with seal, 75 SCM-VIC-8-75 | 8″ with seal, 75 SCM-VIC-8-75 | pcs |
| 98 | Feeding nozzle assembly 9524-00 | 9524-00 | pcs |
| 99 | Drum head coulter (pair) DE-1000 CS10-RA-650-IC | DE-1000 CS10-RA-650-IC | pcs |
| 100 | Outlet pipe 10″(254) SCH 80 | 10″(254) SCH 80 | pcs |
| 101 | Victaulic Seal 10″ (Part VIC-10-75) SCM-VIC-10-GSKT | 10″ (part VIC-10-75) SCM-VIC-10-GSKT | pcs |
| 102 | Victaulic Seal 5″ (Part VIC-5-75) SCM-VIC-5-GSKT | 5″ (part VIC-5-75) SCM-VIC-5-GSKT | pcs |
| 103 | Victaulic Seal 8″ (Part VIC-8-75) SCM-VIC-8-GSKT | 8″ (part VIC-8-75) SCM-VIC-8-GSKT | pcs |
| 104 | Seal built-in support bearings CS10-RA-310-00 | CS10-RA-310-00 | pcs |
| 105 | Oil seal G0006037 | G0006037 | pcs |
| 106 | Mechanical seal SCM-G0006013 (H22451-1A, G0006013) | SCM-G0006013 (H22451-1A, G0006013) | pcs |
| 107 | Outer seal for support bearings CS10-RA-311-00 | CS10-RA-311-00 | pcs |
| 108 | P-type mesh seat seal, high-quality Mongoose SCM-5837001 | SCM-5837001 | pcs |
| 109 | Conveyor Thrust Bearing Seal CS10-RA-312-00 | CS10-RA-312-00 | pcs |
| 110 | Brush belt tensioner assembly with spring EF-RT2007SP | EF-RT2007SP | pcs |
| 111 | Mesh tensioner 14623-00 assembly | 14623-00 assembly | pcs |
| 112 | Clamp Victaulic 2″ hard VIC-2-07 | 2″ hard VIC-2-07 | pcs |
| 113 | Victaulic 5″ clamp with VIC-5-75 seal | 5″ with seal VIC-5-75 | pcs |
| 114 | Lock washer WLSS-63 | WLSS-63 | pcs |
| 115 | Pump body stud and nut G0006032 (H3862-76/3932-61) | G0006032 (H3862-76/3932-61) | pcs |
| 116 | Tape brush 1″x39″ G0002034 | 1″х39″ G0002034 | pcs |
| 117 | Shaft seal brush G0001995 | G0001995 | pcs |
| 118 | Conveyor seal brush 33-1″ G0002033 | 33-1″ G0002033 | pcs |
| 119 | Feeder seal brush 33-1 1/2″ SCM-G0003257 (G0003257) | 33-1 1/2″ SCM-G0003257 (G0003257) | pcs |
| 120 | Feeder seal brush G0003256 | G0003256 | pcs |
Field Derrick PG013 Fault Repair Cases
Case 1: Worn Nozzle Sleeve Reduces Separation Efficiency
A Derrick PG013 centrifuge suffered poor solids separation due to severely worn adjustable nozzle sleeves (P/N SCM-10523-03). Replacing the OEM nozzle sleeves restored proper mud flow and full separation performance.
Case 2: Main Bearing Failure Causes Centrifuge Vibration
Excessive vibration and noise occurred due to a failed main bearing (P/N CS10-RA-512-00) on the solids outlet side. Installing the OEM bearing eliminated vibration and resumed stable centrifuge operation.
Case 3: Mechanical Seal Fluid Leakage
A PG013 centrifuge experienced severe mud leakage from a degraded mechanical seal (P/N SCM-G0006013). Fitting the OEM mechanical seal stopped leakage and protected internal rotating components.
Frequently Asked Questions (FAQ)
| Question | Answer |
| Are these parts exclusively compatible with Derrick PG013 centrifuges? | Yes, all spare parts are custom-designed for Derrick PG013 solids control centrifuges and DE-1000 drum extensions, with OEM-matched part numbers and dimensions for perfect fit. |
| Do these sealing components handle high-solids abrasive drilling mud? | Absolutely, all seals, packing kits, and wear inserts are made from abrasion-resistant materials, designed to withstand harsh high-solids mud conditions without premature failure. |
| Can these parts be used for emergency on-site PG013 repairs? | Yes, every component is designed for quick field installation, making them ideal for emergency breakdown fixes and routine preventive maintenance. |
Procurement Guidance & Call to Action
For solids control maintenance teams, mud system supervisors, and procurement managers managing Derrick PG013 centrifuge fleets, this parts list is the definitive reference to minimize unplanned downtime, uphold API 13C industry standards, and source high-quality, OEM-compatible spare parts. Avoid the risks of substandard generic components, inefficient solids separation, fluid leakage, and costly equipment damage by using this curated catalog as your go-to procurement and technical repair benchmark.
Invest in these durable, precision-engineered Derrick PG013 spare parts to streamline maintenance workflows, resolve on-site failures efficiently, and keep your solids control system operating at peak performance. Each part is built to endure the harsh conditions of 24/7 drilling mud treatment, protecting your equipment investment and ensuring consistent, reliable solids separation and fluid recycling for your rig.
