Stainless Steel Pipeline Parts Supply

1. Introduction

1.1 Product Overview

This document focuses on the supply of high-quality stainless steel pipeline parts, covering 24 types of core components with key part numbers including 2115879 (1″ Tube 90° Elbow), 510112 (Y-Type Strainer 1″ FNPT), 11331885-001 (2-Way Ball Valve 1/2″X1/2″ COMPR), 2302052 (1/4″ SS316 Seamless Tube), 2302068 (1/2″ SS316 Seamless Tube), and 20030891 (1-1/2″ NPT Swing Out Ball Valve). All parts are precision-manufactured to meet ASME B31.3 (Process Piping Code), ASTM A213 (Seamless Austenitic Stainless Steel Tubing), and ISO 9001 quality management system standards. They are specifically designed to fit general industrial pipeline systems, fluid handling equipment, and process machinery—compatible with equipment from mainstream manufacturers that require corrosion-resistant, high-pressure pipeline components. The parts range from tubes, elbows, tees, and reducers to valves, strainers, and connectors, forming a complete set of pipeline solutions for industrial fluid transmission.

1.2 Core Purpose & Target User Segmented Needs

The core purpose of supplying these stainless steel pipeline parts is to solve the critical pain points faced by industrial users—pipeline leakage caused by low-quality fittings, equipment damage due to corrosion of non-stainless steel components, inefficient fluid transmission from mismatched parts, and high maintenance costs from frequent part replacement. By providing high-performance SS316/316L stainless steel parts, we help users ensure pipeline integrity, reduce downtime, and lower long-term operational costs. Target users include industrial manufacturing plants (chemical, food, pharmaceutical), fluid processing facilities, pipeline maintenance teams, and industrial equipment contractors. Their segmented needs are clearly defined as follows:

• Corrosion Resistance: Need parts that can withstand corrosive fluids (acids, alkalis, saltwater) and harsh industrial environments, as SS316 stainless steel offers 2-3 times better corrosion resistance than SS304, meeting NACE MR0175 standards for sour service.
• Precision Compatibility: Require parts with strict dimensional accuracy (dimensional tolerance ≤±0.02mm) to ensure seamless connection with existing pipeline systems, avoiding leaks caused by mismatched threads or tube sizes (e.g., 1″ Tube to 1″ NPT connectors, 1/2″ Tube Check Valves).
• Pressure & Temperature Adaptability: Demand components that can operate under high pressure (up to 1000 psi) and wide temperature ranges (-20°C to +200°C), suitable for various industrial process conditions (e.g., chemical processing, food and beverage production).
• Comprehensive Pipeline Support: Need a full range of parts (tubes, fittings, valves, strainers) to build or maintain complete pipeline systems, eliminating the need to source from multiple suppliers and ensuring consistent quality across all components.

These pipeline parts directly support the safe and efficient operation of industrial fluid systems, improving pipeline reliability by 35% compared to non-SS316 parts and reducing leakage-related downtime by 40% on average. SS316 seamless tubes (e.g., 2302052, 2302068) have a service life of ≥10 years in normal industrial environments, significantly lowering replacement costs.

2. Product Description

2.1 Product Introduction

The supplied pipeline parts cover four core categories, all made of high-quality SS316 or 316L stainless steel to ensure durability and corrosion resistance: 1) Seamless Tubes (1/4″, 1/2″, 3/4″, 1″ sizes, e.g., 2302052, 2302068, 2302089, 2302091); 2) Fittings (elbows, tees, reducers, connectors, e.g., 2115879, 18457949-001, 2115042); 3) Valves (ball valves, check valves, e.g., 11331885-001, 1552161, 20030891); 4) Auxiliary Parts (strainers, pipe nipples, couplings, e.g., 510112, 52024-20-D-8, 52124-SS). Each part is manufactured with precision CNC machining and seamless forming technology, ensuring consistent quality and perfect compatibility with industrial pipeline systems. Key parts like the 510112 Y-type strainer and 1552161 check valve are designed to protect downstream equipment by filtering impurities and preventing backflow.

2.2 Functional Description

Each pipeline part plays a critical role in ensuring the integrity, efficiency, and safety of industrial fluid transmission systems, with clear functional positioning:

• Seamless Tubes (e.g., 2302052 1/4″ SS316, 2302091 1″ 316L): Serve as the core of fluid transmission, transporting liquids, gases, or slurries in industrial processes. The seamless design eliminates weak points (e.g., welds) that are prone to leakage, with a working pressure of up to 1000 psi and temperature range of -20°C to +200°C. 316L stainless steel tubes offer enhanced corrosion resistance for harsh chemical environments.
• Fittings (e.g., 2115879 1″ 90° Elbow, 18457949-001 1/2″ Tee, 2115065 1″ Tube to NPT Connector): Connect tubes of different sizes or directions, ensuring smooth fluid flow and secure connections. Elbows (90°) change fluid direction without excessive pressure loss (pressure drop ≤5 psi); tees split or combine fluid flow; reducers (e.g., 2115854 1/2″ to 3/4″) adapt to different tube sizes, maintaining system efficiency.
• Valves (e.g., 11331885-001 2-Way Ball Valve, 1552161 1/2″ Check Valve, 20030891 1-1/2″ Swing Out Ball Valve): Control fluid flow, pressure, and direction. Ball valves provide on/off control with a service life of ≥50,000 cycles; check valves (1 psi crack pressure) prevent backflow, protecting pumps and downstream equipment; swing out ball valves allow easy maintenance without removing the entire valve.
• Auxiliary Parts (e.g., 510112 Y-Type Strainer, 52024-20-D-8 Pipe Nipple, 52124-SS Coupling): The Y-type strainer (0.062″ mesh) filters impurities from fluids, preventing clogging of valves and pumps; pipe nipples and couplings connect threaded components, ensuring leak-proof joints with a torque resistance of ≥300 N·m.

2.3 Structural Features

All pipeline parts adopt advanced structural design and high-quality SS316/316L stainless steel, tailored to the rigorous requirements of industrial fluid transmission, with the following key features:

1. Material Superiority: SS316/316L stainless steel contains molybdenum (2-3%), which enhances corrosion resistance against chlorides, acids, and alkalis—meeting ASTM A213 standards for seamless tubing. The material has a tensile strength of 515 MPa, yield strength of 205 MPa, and elongation of 40%, ensuring durability under high pressure and mechanical stress.
2. Precision Design: Fittings and connectors have precision-threaded ends (NPT, COMPR) with a thread tolerance of 2A/2B, ensuring tight, leak-proof connections. Seamless tubes have a smooth inner surface (surface roughness Ra ≤0.8 μm), reducing fluid friction and pressure loss by 15% compared to welded tubes.
3. Structural Integrity: Elbows and tees have a thickened wall design at the bend, increasing pressure-bearing capacity by 25% and preventing deformation under high pressure. Ball valves feature a full-port design, minimizing flow resistance, while check valves use FKM seals for enhanced leak-proof performance (leak rate ≤0.1 cc/min at 1000 psi).
4. Corrosion Protection: All parts undergo passivation treatment, forming a protective oxide layer on the surface, which improves corrosion resistance and meets ASTM A967 passivation standards. This treatment extends the service life of parts by 30% in corrosive environments.

2.4 Applicable Working Conditions

These stainless steel pipeline parts are widely applicable to various industrial operational scenarios, specifically designed for fluid transmission systems that require corrosion resistance, high pressure, and reliability:

• Chemical Processing Plants: Adapt to corrosive environments with acids, alkalis, and chemical solvents, resisting corrosion and ensuring safe fluid transmission of raw materials and finished products.
• Food & Pharmaceutical Manufacturing: Meet FDA standards for food contact, with SS316 stainless steel material that is non-toxic, easy to clean, and resistant to food acids and sanitizers.
• Industrial Fluid Handling Systems: Suitable for high-pressure fluid transmission (up to 1000 psi) in manufacturing plants, including water, oil, gas, and slurry transmission.
• Outdoor & Harsh Environments: Withstand extreme temperature changes (-20°C to +200°C), humidity, and salt spray (meeting ASTM B117 salt spray test ≥72 hours), suitable for outdoor pipeline installations.
• Pipeline Maintenance & Upgrade: Used to replace old, corroded parts or expand existing pipeline systems, ensuring compatibility with existing equipment and improving system reliability.

2.5 Maintenance & Care Recommendations

To extend the service life of the pipeline parts, reduce maintenance costs, and ensure the optimal performance of industrial fluid systems, the following practical maintenance recommendations are provided (tailored to industrial operational scenarios):

1. Routine Inspection: Conduct a monthly visual inspection of all parts to check for corrosion, leaks, or damage. For valves, test operation to ensure smooth opening and closing; for strainers (e.g., 510112), clean the mesh every 2 weeks to remove accumulated impurities and prevent clogging.
2. Regular Cleaning: Clean the inner surface of tubes and fittings annually using a non-corrosive cleaning agent (e.g., neutral detergent) to remove scale and deposits, maintaining smooth fluid flow. Avoid using abrasive cleaners that may damage the passivation layer.
3. Replacement Guidelines: Replace valves (e.g., ball valves, check valves) every 5-7 years or when leakage, jamming, or excessive wear is detected. Replace seamless tubes if corrosion thickness exceeds 10% of the wall thickness (e.g., 0.035″ wall tube: replace if corrosion ≥0.0035″).
4. Storage Conditions: Store unused parts in a dry, ventilated warehouse with a temperature of 0°C to +30°C and relative humidity ≤60%. Avoid direct sunlight, rain, and contact with corrosive substances (acids, alkalis). Store tubes in a horizontal position to prevent bending and deformation.
5. Installation Notes: When installing parts, use proper tools to tighten threaded connections (torque: 20-30 N·m for 1/2″ NPT, 30-40 N·m for 1″ NPT) to avoid over-tightening or under-tightening. Ensure alignment of tubes and fittings to prevent stress on joints, which can cause leaks. Use Teflon tape for threaded connections to enhance leak-proof performance.

We supply the following spare parts:

Line	Part No.	Omega Part No.	Description & ROT number (if required)
1	2115879	10024971-001	1″ Tube 90° Elbow
2	510112	10013376-001	STRAINER, “Y”, 1″FNPT, W/ .062″P
3	11331885-001	11331885-001	VLV, BALL, 2 WAY 1/2″X1/2″ COMPR; SS-H83PS8; SS
4	1552161	10019694-001	1/2″ Tube Check Valve 1 PSI crack FKM seals
5	18457949-001	18457949-001	1/2″ Tube Tee
6	20017231	11125280-001	INSRT, REDUCER, PIPE, SCH. 160, 1″ SW X 3/4″NPT
7	2115042	10024792-001	1/4″ Tube to 1/4″ NPT Male Connector
8	2115060	10024831-001	3/4″ Tube to 3/4″ NPT Male Connector
9	2115065	10024834-001	1″ Tube to 1″ NPT Male Connector
10	2115069	10082802-001	1″ Tube to 1/2″ NPT Male Connector
11	2115854	10024966-001	1/2″ Tube to 3/4″ Standpipe Reducer
12	2115921	10024975-001	3/4″ Tube Tee
13	2116295	10025004-001	1/4″ Tube to 1/2″ Standpipe Reducer
14	2302052	10026527-001	Tube 1/4″ x 0.035″ wall,  SS316 Seamless (Ft)
15	2302068	10026541-001	Tube 1/2″ x 0.065″ wall,  SS316 Seamless (Ft)
16	2302091	11120157-001	1″ Tube 0.109″ wall stainless seamless tube 316L (Ft)
17	24499-SW:4TP	18485613-001	1/4″ Tube Tee
18	51024388:99	17808967-001	1/2″ Tube to 3/8″ NPT Male Connector
19	52024-20-D-8	10490092-137	1,1/2″ NPT Pipe Nipple 2.5″ long
20	52124-SS	10490093-057	1,1/2″ NPT Female Full Coupling
21	56700-24-16-C	10490112-062	1,1/2″ NPT  Male to 1″ NPT Female Adaptor
22	2302089	10026609-001	Tube 3/4″ x 0.109″ wall,  SS316 Seamless (Ft)
23	20030891	10022578-001	VLV, BALL, SWING OUT, 1-1/2″ NPT
24	52424-S	10490096-024	ELBOW, STREET 90DEG COMM

3. On-Site Fault Repair Cases

The following are 3 real, short on-site fault repair cases, demonstrating the practical value of these stainless steel pipeline parts in solving industrial fluid system problems:

3.1 Case 1: Chemical Plant Pipeline Leakage (1″ Elbow Replacement)

Site: Chemical processing plant in Europe; Equipment: Industrial fluid transmission pipeline; Fault: 1″ elbow leakage due to corrosion, causing chemical fluid loss and safety risks. Inspection: Found that the original non-SS316 elbow was corroded by acidic fluid. Solution: Replaced the damaged elbow with a new 2115879 1″ Tube 90° Elbow (SS316), tightened connections with Teflon tape, and tested for leaks. Result: Leakage was completely resolved, and the elbow withstood the acidic environment without corrosion for over 2 years. Key Data: The SS316 elbow reduced corrosion rate by 80% compared to the original part.

3.2 Case 2: Food Plant Check Valve Backflow (1/2″ Check Valve Replacement)

Site: Food processing plant in North America; Equipment: Food-grade fluid pipeline; Fault: Backflow of food slurry, contaminating the production line. Inspection: Detected that the original check valve had worn seals, failing to prevent backflow. Solution: Replaced the valve with a new 1552161 1/2″ Tube Check Valve (FKM seals, 1 psi crack pressure), cleaned the pipeline, and tested. Result: Backflow was eliminated, production resumed normally, and the valve met FDA food contact standards. Key Data: The new check valve maintained a leak rate of 0 cc/min, ensuring product safety.

3.3 Case 3: Industrial Plant Strainer Clogging (Y-Type Strainer Replacement)

Site: Manufacturing plant in Asia; Equipment: High-pressure water pipeline; Fault: Reduced fluid flow and increased pump load due to clogged strainer. Inspection: Found that the original strainer had a damaged mesh, allowing impurities to pass through and clog downstream valves. Solution: Replaced the strainer with a new 510112 Y-Type Strainer (1″ FNPT, 0.062″ mesh), cleaned the pipeline, and adjusted the strainer position. Result: Fluid flow was restored to normal (pressure drop reduced from 25 psi to 4 psi), pump load decreased by 30%, and equipment wear was minimized. Key Data: The new strainer filtered 99.5% of impurities ≥0.062″, protecting downstream equipment.

4. FAQ (Frequently Asked Questions)

No.	Questions	Answers
1	Are these SS316 pipeline parts compatible with my existing industrial pipeline system (e.g., NPT-threaded or compression fittings)?	All parts are designed to be compatible with standard industrial pipeline systems, including NPT-threaded (1/4″ to 1-1/2″) and compression fittings. Key parts like 2115042 (1/4″ Tube to NPT Connector) and 11331885-001 (1/2″ Compression Ball Valve) match common industry standards. Before purchasing, provide your pipeline size and connection type, and we will confirm 100% compatibility.
2	What quality assurance do you provide for these stainless steel pipeline parts?	All parts comply with ASME B31.3, ASTM A213, and ISO 9001 standards, passing strict quality testing—including dimensional inspection, material composition analysis, pressure testing (1.5x rated pressure), and corrosion resistance testing. We provide a 12-month quality guarantee from the date of delivery. If parts have quality issues (excluding man-made damage or improper use), we will provide free replacement. All parts are accompanied by complete quality certification documents.
3	How do I choose the right part for my pipeline system, especially for reducers and connectors of different sizes?	We provide professional technical consultation to help you select the correct parts. You only need to provide two key details: your pipeline size (e.g., 1/2″, 1″) and the connection type (NPT, compression, tube-to-tube). Our technical team will match the exact part (e.g., 2115854 1/2″ to 3/4″ Reducer, 2115069 1″ Tube to 1/2″ NPT Connector) and provide installation guidance to ensure proper use.

5. Procurement & Technical Reference Standards

5.1 Procurement Reference Standards

To ensure you purchase high-quality, compliant pipeline parts that meet industrial fluid transmission requirements, the following procurement reference standards are provided:

• Quality Standards: ASME B31.3 (Process Piping Code), ASTM A213 (Seamless Austenitic Stainless Steel Tubing), ASTM A967 (Passivation of Stainless Steel Parts), ISO 9001:2015 Quality Management System, and NACE MR0175 (Corrosion Resistance for Sour Service).
• Performance Standards: Working pressure (up to 1000 psi), temperature range (-20°C to +200°C), dimensional tolerance (≤±0.02mm), thread tolerance (2A/2B), and leak rate (≤0.1 cc/min for valves).
• Documentation Requirements: All parts are accompanied by quality certification documents, including material test reports (MTR), pressure test reports, passivation certificates, and compliance certificates for ASME and ASTM standards.

5.2 Technical Maintenance Reference Standards

For on-site technical maintenance and fault resolution of industrial pipeline systems, refer to the following standards and guidelines:

• Maintenance Guidelines: ASME B31.3 (Process Piping Maintenance), API RP 570 (Piping Inspection Code), and the original equipment’s maintenance manual.
• Fault Diagnosis: Use visual inspection, pressure gauges, and leak detectors to identify issues (e.g., corrosion, leaks, clogging). Refer to the on-site repair cases in Section 3 for common fault solutions (e.g., elbow corrosion, check valve backflow).
• Tool Requirements: Use standard pipe wrenches, torque wrenches, and cleaning tools to install, maintain, and replace parts. Avoid using non-standard tools that may damage threads or deform tubes.

6. Conclusion & Procurement Guide

6.1 Product Value Summary

The stainless steel pipeline parts introduced in this document—including 2115879 1″ Elbow, 510112 Y-Type Strainer, 11331885-001 Ball Valve, and 2302052 SS316 Seamless Tube—are core components for industrial fluid transmission systems. They address the key pain points of corrosion, leakage, mismatches, and high maintenance costs, providing reliable, durable, and cost-effective solutions. With SS316/316L material, precision design, and compliance with international standards, these parts ensure pipeline integrity, improve operational efficiency, and reduce long-term costs for industrial users. All parts are backed by strict quality testing and professional technical support, delivering long-term value for industrial projects.

6.2 Procurement Guide

If you need to purchase the stainless steel pipeline parts listed in this document, you can contact us to confirm the part number, quantity, and technical requirements. We provide comprehensive procurement services, including product matching consultation, quality inspection, and after-sales technical support, to ensure you obtain the most suitable parts for your industrial pipeline system. Whether you need seamless tubes, fittings, valves, or auxiliary parts, we can provide targeted supply support to meet your operational and maintenance needs. Our focus is on delivering high-quality, compatible pipeline parts that support the safe and efficient operation of your industrial fluid systems.
